Home > Products > Cutting Machines > Good Quality in Sale Paper Cutting Machine QZYK-920
Good Quality in Sale Paper Cutting Machine QZYK-920
- Ningbo
- T/T
You May Like
Product Details
| Condition | New | Type | Paper Cutting Machine | |
| Computerized | Yes | Place of Origin | Zhejiang, China | |
| Brand Name | ShenVII | Model Number | QZYK-920 | |
| Voltage | 380V | Power(W) | 3KW | |
| Dimension(L*W*H) | 2300*1400*1910 | Weight | 2700kg | |
| Certification | CE/ISO9001 | Warranty | One Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Good quality in sale paper cutting machine QZYK-920
Series adopts 7 inches True Color Touch screen, and the imported servo system adopts PLC controller, max.speed can reach 18m/min, positional accuracy +0.01mm,favor multi-language, and its control system is the most advanced with imported components, like “Omron”. “Schneider”, “LG”,etc. Equipped with linear double guide and ball screw from Taiwan.
Technology Data | ||||||
Model | 670 | 920 | 1150 | 1300 | 1370 | 1680 |
Max width of cutting | 670mm | 920mm | 1150mm | 1300mm | 1370mm | 1680mm |
Max length of cutting | 670mm | 1100mm | 1150mm | 1300mm | 1450mm | 1680mm |
Max. Heigth of cutting | 80mm | 130mm | 165mm | 130mm | 165mm | 150mm |
Max pressing of paper | 4000N | 35000N | 40000N | 40000N | 45000N | 80000N |
Cutting speed | 40time/min | 45time/min | 45time/min | 45time/min | 45time/min | 44time/min |
Power of main motor | 2.2kw | 3kw | 4kw | 4kw | 4kw | 4.5kw |
Wind pump motor power | / | 0.55kw | 0.75kw | 0.75kw | 0.75kw | 0.75kw |
Feed motor power | 0.4kw | 0.55kw | 0.55kw | 0.55kw | 0.55kw | 0.75kw |
weight | 550kg | 2700kg | 3800kg | 3800kg | 4500kg | 6500kg |
Over dimensions L*W*H
| 1500*1300*1450 | 2300*1400*1910 | 2750*1400*1910 | 2800*1400*1910 | 2950*1400*2000 | 3250*3200*1850 |
Width of the machine | 1200mm | 2420mm | 2800mm | 2870mm | 2420mm | 3100mm |
Machine width excluding | / | 1720mm | 2160mm | 2160mm | 2364mm | 2900mm |
Length(cm/inches) | 1300mm | 2180mm | 2490mm | 2490mm | 2770mm | 3000mm |
Front table length | 500mm | 650mm | 715mm | 715mm | 730mm | 760mm |
Table height | 850mm | 900mm | 900mm | 900mm | 900mm | 900mm |
Voltage | V361-399 | V361-399 | V361-399 | V361-399 | V361-399 | V361-399 |
Wire size (mm2) | 2.5m2 | 2.5m2 | 2.5m2 | 2.5m2 | 2.5m2 | 4m2 |
About series
EW series adopts 10.4 inches True Color Touch screen, and the imported servo system adopts PLC controller, max. Speed can reach 18m/min, positional accuracy +0.01mm,favor multi-language, and its control system is the most advanced with imported components, like “Omron”. “Schneider”, “LG”,etc. Equipped with linear double guide and ball screw from Taiwan.
QZYK-0920EW
QZYK-1300EW
QZYK-1370EW
QZYK-1680EW
DE Series adopts 7”color screen and frequency inverter (servo system for your option) from Taiwan, max.paper pushing speed is 10m-15m/min, dynamic display cutting and operating conditions, program memory can reach 2000times.Equipped with “Omron”, “Schneider”, ‘LG”, etc. Imported components, convenient blade changing device, and blade bed rod safety bolt overload protection.
QZYK-0920DE
QZYK-1300DE
QZYK-1370DE
QZYK-1680DE
D Series adopts LCD digital display system which can protect operator’s eyes effectively, expand its lifespan, and display cutting parameters. Paper feeder adopts linear double linear guide with highprecision grinding T shape leas screw, which highly guarantees positioning accuracy of feeder’s. The machine adopts infrared protection device, hands linkage button, safe and convenient blade changing device, blade bed rod safety bolt overload protection, which make the machine be a ideal cutter with high performance.
QZYK-0920D
QZYK-1300D
QZYK-1370D
QZYK-1680D
About our company
Zhejiang Shenvii Machinery Co,Ltd.Was approved by the Zhejiang Administration for Industry&Commerce and issued under license in 2005,with the company registered capital of 5.19million RMB.
The company specializes in printing and packaging equipment, which is widely applied in daily necessities, food, chemicals, clothing, medical packaging, beverage packaging industry etc.The company is experienced in cooperating with dozens of professional R&D team, capable pf re-designing and improving clients’ requirements for products. Last but not least, the company boasts a professional aftersales service team who can provide customers with comprehensive solutions and technical support.We are promised to show you all the running conditions of equipment in which you are interested.
Q: where is your company lacated? How can I visit there?
A:Our company is located in Ruian City,Zhejiang Province, China.
It is about 40 minutes by plane or 5 hours by train from Shanghai to Ruian.
Q;How can I get some samples?
A:We are honored to offer you samples
Q:What's the main product of your company?
A:We are the specialist in these four lines:Plastic Production Line, Paper Cup Production Line,
Paper Bag Production Line and Non Woven Fabric Production Line.
More About our factory
