Home > Products > COLLER TYPE VERTICAL FFS MACHINE > HIGH SPEED FFS PACKAGING MACHINE
HIGH SPEED FFS PACKAGING MACHINE
- Nhava Sheva
- T/T D/P D/A
You May Like
Product Details
| Condition | New | Application | Food, Commodity, Medical, Chemical | |
| Packaging Type | Other, WOODEN PALLETS | Packaging Material | Wood | |
| Automatic Grade | Automatic | Driven Type | Pneumatic | |
| Voltage | 440 V | Power | 5 KW | |
| Place of Origin | Haryana, India | Brand Name | CHIRAG | |
| Model Number | CH- 100V1 | Weight | 650Kg | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
OUR HIGH SPEED AUTOMATIC VERTICAL FFS MACHINE WITH AUGER FILLING SYSTEM IS SUITABLE TO PACK ALL TYPES OF STICKY POWDERS.
The chirag electronics series CH-100V1 is high speed bagger to pack various products. It is suitable to pack spices, milk powder, glucose, tea, coffee, rice, salt, sugar, snacks & dry fruits.
Filling Range: 10gm to 250gm.
Features:
Controlled by PLC with color touch screen.
Servo drive in auger filling/Servo drive for pulling paper.
Self diagnostic features.
Easy loading of film roll.
No product no fill to ensure no wastage of bags.
Safety doors interlocked.
Password protection.
Fault history.
Technical specification:
Bag Width: 60 to 225mm
Out put: 80 T0 90 Bags/Min.
Max. roll dia: 480mm
Bag type : Center seal
Supply voltage: 415V, 3phase, 50 Hz
Power requirement: 5.5Kw
Air requirement: 6kg/cm2
Machine weight: 1500kg.
Machine dimension: 7' * 4' * 9'
