Kaishan water equipment
- Xiamen
- T/T Credit Card
You May Like
Product Details
| Condition | New | Type | Other, water well drilling rigs | |
| Power Type | Diesel | Place of Origin | Fujian, China | |
| Brand Name | ZHAOXING | Model Number | KW10 | |
| Usage | Water Well | Voltage | 24V | |
| Power(W) | 58KW/80HP | Dimension(L*W*H) | 5100*2300*2700 | |
| Weight | 6500kg | Certification | CE, CE | |
| Warranty | 1 Year-2000hours | After-sales Service Provided | Overseas service center available |
Product Description
Specifications
water equipment1.17 years engineering experience
2.Under ISO9001 quality management system
water equipment
Features :
Water Well drilling rig characteristics:
1.Safe and stable travelling system
2.Powerful and reliable engine
3.Latest design drilling boom
4.Powerful feeding and rotating system
5.Multi-angle operation
6.Delivery fast (10-14days) Portable Water Well Drilling Rigs
| Parameter Technique: | |||
| Model | KW10 | KW20 | KW30 |
| DIA.hole | Φ115-254 | Φ152-260 | Φ168-300 |
| Drilling depth | 120m | 200m | 300m |
| Air consumption | 16-30m3/min | 16-30m3/min | 16-40m3/min |
| Working pressure | 10.5-24.6bar | 10.5-24.6bar | 1.05-2.46 |
| Ground clearance | 245mm | 280mm | 280mm |
| Support cylinder stroke | 460mm | 1000mm | 1000mm |
| Feed cylinder stroke | 1750mm | 2400mm | |
| Feed power | 30000N | 45000N | 50000 |
| Lift power | 70000N | 95000N | 150000 |
| Speed of rotator | 50-100rpm | 60-105rpm | 43/52/69 |
| Rotation torque | 3200N.m | 40000N.m | 40000N.m |
| Climb capacity | 15 | 25 | 25 |
| Traveling speed | 0-2.5KM/h | 0-2.5KM/h | 0-2.5KM/h |
| Recommended compressor | RHP750 | RHP750 | RHP750 |
| Engine | |||
| Engine model | YC4D80 | YC6B125-K10 | YC6B150Z-T21 |
| power | 58KW/80HP | 92KW/122HP | 110Kw |
| Rotation speed | 2400rpm | 2200rpm | 2100rpm |
| Drilling components | |||
| Hammer | DHD360(DTH380) | DHD360(DTH380) | DHD360(DTH380) |
| DIA. Of rod | Φ89mm | Φ89mm | Φ89-102mm |
| Length of rod | 3m | 3m | 3m |
| DIA.hole | Φ115-254 | Φ152-260 | Φ168-300 |
| Weight | 6500kg | 8500kg | 9500kg |
| Dimension | 5100*2300*2700 | 5100*2300*2850 | 5200*2300*3200 |
Air compressor
Drilling rig
drill hammer and bit
Production Process
When you want to purchase equipment, we can supply best configuration according to your project situation.
When you want to improve increase efficiency, we can supply reform project for you.
When you want to decrease drilling tool cost, we can supply good quality and low price product to you.
When your equipment need to repair, we can supply technical service.
In a word, if you cooperation with me, you will get benefit as soon as possible.
Our Certificate
Not only are we one of the premier suppliers of DTH equipment, we have also become specialists in solution based large diameter rock drilling packages, providing not only large diameter hammers and bits, but also shrouded drill pipes, helicoidal pipes and casing advancing systems. Working with you from tender stage to contract completion helps you get your projects completed on time and on budget.
