Semi-Hermetic Screw Compressor Middle Temperature Compressor Racks for ice making,chillered water making.etc

Specifications

Semi-Hermetic Screw Compressor Middle Temperature aCompressor Racks for ice making,chillered water making.etc

JZHLG Series Semi-Hermetic Screw Compressor Middle
Temperature Compressor Racks(With Hanbell Screw Compressor)

Products Description

    With the rapid development of the refrigeration equipment market, large preservation storages, low-temperature freezing storage, ice making equipment are more and more used. JZHLG series products feature by their structures of multi-Hanbell compressors paralleled together to form one intergrated systems. This products are applicable to large size and rooms, ice making, chilled water making etc with temperature requirement ranging 5°C~5°C and -20°C~-15°C. The products are equipped with muti protection devices for wrong direction, overheating,overloading, overhigh discharging temperature, overlower oil level, oil flow, and high and low pressure etc. The refrigeration system has multi-phase cap regulation system to save energy significantly.

Features

-Used new type 5:6 asymmetric rotor semi-closed screw compressors, high efficiency, long life, low noise, etc.
-Adopted the change of cooling load to multi-lever energy regulation, effectively reduce energy consumption.
-Compressor coil temperature protection; exhaust temperature protection; low oil levels; Hydraulic differential protection; High&Low Pressure Portection

 Model Details:
--Water Cooled Single Compressor Series R22 Units
1.Temperature:-5°C~5°C                    Models: JZHLGS-30M---JZHLGS-150M(30HP-150HP)
2 Temperature: -20°C~-15°C             Models: JZHLGS-30L---JZHLGS-150L(30HP-150HP)
--Water Cooled 2 Compressors Series R22 Units
3.Temperature:-5°C~5°C                    Models: JZHLGS2-60M---JZHLGS3-220M(60HP-220HP)
4.Temperature:-20°C~-15°C              Models: JZHLGS2-60L---JZHLGS3-250L(60HP-250HP)
--Water Cooled 3 Compressors Series R22 Units
5.Temperature:-5°C~5°C                    Models: JZHLGS3-90M---JZHLGS3-210M(90HP-210HP)
6.Temperature:-20°C~-15°C              Models: JZHLGS3-90L---JZHLGS3-300L(90HP-300HP)
--Air Cooled Single Compressor Series R22 Units
1.Temperature:-5°C~5°C                    Models: JZHLGF-30M---JZHLGF-150M(30HP-150HP)
2.Temperature: -20°C~-15°C             Models: JZHLGF-30L---JZHLGF-150L(30HP-150HP)
--Air Cooled 2 Compressors Series R22 Units
1.Temperature:-5°C~5°C                    Models: JZHLGF2-60M---JZHLGF2-250M(60HP-250HP)
2.Temperature: -20°C~-15°C             Models: JZHLGF2-60L---JZHLGF2-250L(60HP-250HP)
--Air Cooled 3 Compressors Series R22 Units
1.Temperature:-5°C~5°C                    Models: JZHLGF2-90M---JZHLGF2-240M(90HP-240HP)
2.Temperature:-20°C~-15°C              Models:JZHLGF3-90L---JZHLGF3-300L(90HP-300HP)

Technical Data Sheet for Water Cooled Semi-Hermetic Screw Compressor Racks (part)

Models Specifications :

 JZ   H   LG   F   2 --  100   M   F   Y
Notes: JZ:LVTE Company Products Code      H:Products Series Code
LG:Compressor Type Code: LG—Semi-closed screw comprssors        F:Cooling Way: F—Air-Cooled; S—Water-Cooled
2:Compressor Quantity:Others—Signle       100:Compressor power input(HP)
M:Temperature Code:M—Temperature:-5°C~8°C;L—Temperature:-20°C~-15°C

F:Compressor Model:F-Fusheng;Others—Hanbell
Y:Refrigerant:Y—R404A;A—R410A;C—R407C;Others—R22

1.Water Cooled Single Compressor Series R22 Units

  Design Working Condition: Evaporation Temperature -7°C;Cooling Water Temperature In/Out 30°C/35°C.
Temperature:-5°C~5°C.

  Technical Data Sheet for Air Cooled Semi-Hermetic Screw Compressor Racks (part)

  Air Cooled Single Compressor Series R22 Units

 Design Working Condition: Evaporation Temperature -7°C;Ambient Temperzture 35°C.Temperature:-5°C~5°C.
