Crawler Excavator CUMMINS Excavator
Negotiable
/ Set
1 Set(Min. Order)
- Shanghai Port/Tianjin Port/Qingdao Port-
- T/T L/C
You May Like
-
LT623B Single Drum Daul-amplitude Vibratory Roller
-
(Construction Machinery)7 Ton Hydraulic Crawler Excavator
-
Crawler Excavator
-
Construction Machienry Mini Excavators Privdied by Factory With Lower Price
-
Construction Machienry Mini Excavators Privdied by Factory With Lower Price
-
Mini Excavator Price List Privdied by Factory Directly
Product Details
| Place of Origin | Henan, China | Brand Name | LuTong | |
| Model Number | LT230-6 | Condition | New | |
| Moving Type | Crawler Excavator | Operating Weight | 6800kg | |
| Bucket capacity | 1.0~1.2m³ | Maximum Digging Height | 9388mm | |
| Maximum Digging Depth | 6758mm | Machine Weight | 23000Kg | |
| Max Digging Radius | 6387mm |
Product Description
Specifications
1.Crawler Excavator Imported CUMMINS enginee;2.Excavator water-cooled.direct-spary.4 storke
| Crawler Excavator: Engine | ||
| Model | Imported CUMMINS 6BTA5.9 enginee | |
| Type | Water-cooled .direct-spary.4 storke | |
| BoreXstorke | 106mmX 125 mm | |
| Displacement | 5.9 L | |
| Rated power | 125kw/2000.rpm(ISO9249) | |
| Governor | all speed control | |
| Crawler Excavator: Hydraulic System | ||
| Main pump | Negative flow+Cross power system | |
| Max.flow | 2X238L | |
| Hydraulic motor | ||
| Propel hydraulic motor | Two axial-pison motors | |
| Swing hydraulic motor | Axial-piston motors | |
| Swing circuit | 30Mpa | |
| Control circuit | 4.2Mpa | |
| Boom | 2-&125X1290X&85 | |
| Cylinder | ||
| Crawler Excavator: Swing Syetem | ||
| Parking brake | When swing control rod in the neutral automatic hydraulic lock | |
| Tail swing radius | 2130 mm | |
| Swing ball bearing | Heavy load.sealed oil lubrication | |
| Fuel tank | 220L | |
| Hydraulic oil tank | 80L | |
| Cool ant | 20L | |
| Travel drive | 2X3.5L | |
| Swing drive | 3.8L | |
| Air conditioner | 1kg | |
| Operating weight | 23000kg | |
| Crawler Excavator: Cylinger | ||
| Bore X Stroke X diameter | ||
| Boom | 2XΦ125X1290X85(mm) | |
| Arm | Φ140X1510X100(mm) | |
| Bucket | Φ125X1055X85(mm) | |
| Blade | Φ100X852X75(mm) | |
