Wheeled Tractor90HP 2WD With Good Performance Producted by Factory

Type

LYH900

        LYH904

Model

4*2 (double-wheel driving)

4*4 (4-wheel driving)

Dimension (mm)

Length (with front loading)

4080

4396

Width

2038

2038

Height (to vent)

2810

2810

Wheelbase (mm)

2195

2195

Front-wheel tread (mm)

1385~1685 (1485 in common use)

1610

Rear wheel tread (mm)

1620~2020 (1620 in common use)

The smallest ground gap (mm)

476

Agriculture ground gap (mm)

396

379

Turning radius

   (m)

5.1

5.6

not apply the brake with single side

The whole tractor mass (kg)

structure mass

3350

3750

the smallest using mass

3100

3500

Loading mass

front loading

3590

3990

rear loading

3340

3740

Rated traction (KN)

17.7

21.3

Engine type

4110T90

Marked power (KW)

66.2

Clutch

10 inch double action

Gear box

Shift combination style. Mesh cover shift

Speed range

2.4-31.9

Centre turn

Spire and taper sub-gear

Different speeder

Double planet wheels, close style

Different speed lock

Post and pin style

Final transmission

Planet gear style

Front driving bridge

 Full closed prick gear style (for types with 4- wheel driving )

Independent driving box

   Column gear with straight teeth (for types with 4-wheel driving )

Front wheel table specification

7.5-16

11.2-24

Rear wheel table specification

13.6-38

Redirector type

Mechanical or hydraulic turning

Arrester type

Arrester with double pieces of oil-bath tray (mechanical style)

Lifter type

Semi-separation

Control way to plough depth

Force, place control and floating control

Hanging device type

Three point hanging with postposition

Driving output axis turning speed (r/min)

540/760
