Home > Products > Motor Grader > PY165C(ROAD MACHINERY) Hydrodynamic self-propelled motor grader

PY165C(ROAD MACHINERY) Hydrodynamic self-propelled motor grader

FOB Price

USD $1 - $1,000,000 / Unit

1 Unit(Min.Order)

Port shanghai/qingdao
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New		Place of Origin	Henan, China
Brand Name	lutong		Model Number	PY220C PY180C PY180D PY165C PY135C

Product Description

Specifications

1.Hydraulic vibratory roller use CUMMINS
2.we are the main manufacturer of China.
3.CE certification

Hydraulic vibratory roller

1.Torque converter and power-shift gearbox introduced from GERMANY ZF inc. are integrated together Six forward gears and three backward gears meet various requirements.
2.Driving axle with integrated free-wheel anti-slip differential and strong roller chain drive tandem case, Boxed oscillated steering front axle with leaned wheels.
3.Popular working mechanism with pendulum-arm connecting rod structure,Standard equipped free-maintenance rolling-plarecircle device. Double cylinders of the blade tip control can adjust the cutting angle depending on soil quality.
4.Flexible hydraulic control system with two sets of HUSCO five way control valve, lmported hydraulic equalizing valve for the bladelifting,Patent hydraulically-operated pin drawing device is designed firstly in board.
5.Hydraulically operated with entire instrumental monitoring system, Free-maintenance OPTIMA.

Main TechnicaParameters
MODEL		PY220C	PY180C/PY180D	PY165C	PY135C
Operation mass	kg	16900	16000	15000	11000
Front axle load	kg	5820	5150	4150	3045
Rear axle load	kg	11080	10850	10850	7955
Max.forward speed	km/h	36.8	38.2/36.8	40.4	42
Max.backward speed	km/h	24.8	24.5/24.8	25.7	30
Speed geae number		F6/R3	F6/R3	F6/R3	F6/R3
Turning radius	mm	7800	7800	7500	6600
Hydraulic system pressure	Mpa	18	18	18	16
Blade length×height	mm	3965*610	3965*610	3660*610	3710*610
Front wheeltrack	mm	2150	2150	2150	2150
Rear wheeltrack	mm	2340	2340	2340	2267
Wheelbase	mm	6362	6362	6062	5780
Engine model		6CTA8.3	6BTA5.9/SC8D180	6BTA5.9	6BT5.9
Engine power	KW	160	132/140	125	110
Overall dimensions	mm	858527903340	858527903340	828527903340	801523803050
