CL-FF050SB electrical dc motor
Negotiable
/ Piece
1000 Pieces(Min.Order)
- 30000 Unit / Units per Month
- Hong Kong
You May Like
-
12V dc motor CL-RS380PH brush dc motor for vacuum cleaner, electric drill, screwdriver
-
Chaoli CL-1013 Coreless DC Motor
-
CL-RS550 brush dc motor for electric drill, air compressor
-
flat motor CL-FF130 for rc toys
-
high speed CL-1013 coreless micro dc motor for home appliance
-
Helicopter dc motor, CL-FF180
Product Details
| Brand Name | chaoli | Model Number | CL-FF050SB | |
| Usage | Home Appliance | Certification | ROHS | |
| Type | Micro Motor | Torque | 8.5 g.cm | |
| Construction | Permanent Magnet | Commutation | Brush | |
| Protect Feature | Totally Enclosed | Speed(RPM) | 10400rpm/min | |
| Continuous Current(A) | 0.046A | Output Power | 0.73W | |
| Voltage(V) | 7.0V | Efficiency | IE 2 |
Product Description
Specifications
1.Shaft Diameter: 1.5 mm2.motor cans Length: 26.9 mm
3.Voltage range:2.0~8.0V
4.motor diameter:15.5mm
dc motor
CL-FF050SB DC Motor
| MODEL | VOLTAGE | NO LOAD | AT MAXIMUM EFFICIENCY | STALL | ||||||||
| OPERATING RANGE | NOMINAL | SPEED | CURRENT | SPEED | CURRENT | TORQUE | OUTPUT | TORQUE | CURRENT | |||
| r/min | A | r/min | A | mN.m | g.cm | W | mN.m | g.cm | A | |||
| CL-FF050SB-11170 | 2.0-8.0 | 7 | 10400 | 0.046 | 8440 | 0.2 | 0.83 | 8.5 | 0.73 | 4.41 | 45 | 0.85 |
| CL-FF050SB-09250 | 5.0-11.5 | 8 | 8100 | 0.023 | 6610 | 0.1 | 0.63 | 6.4 | 0.44 | 3.34 | 35 | 0.45 |
Certification
CL-FF050SB dc motor CL-FF050SB 7v dc motor dc motor
dc motor micro dc motor electric car dc motor
