High Pressure Water Test Pump Hydraulic Pressure Test Equipment
- qingdao
You May Like
-
Hydrostatic Pressure Testing Pumps Pressure Test Hydraulic Pump
-
GYB-3 1000bar Manual Water Pressure Test Pump Pressure Testing Pump
-
Hydrostatic Pressure Testing Pumps Hydrostatic Test Equipment
-
Pipe Hydraulic Pressure Test Equipment Water Pressure Testing Equipment
-
High Pressure Testing Pump High Pressure Water Pressure Test Pump
-
100-500 Bar Water Pressure Test Machine High Pressure Testing Machine
Product Details
| Theory | Reciprocating Pump |
Product Description
Specifications
hydraulic pressure test equipment1. Pressure: 90~500bar
2. Nominal Flow : 40~170L/min
3.Engine: electric or diesel
high pressure water test pump hydraulic pressure test equipment
Specifications of the water pressure test pump hand operated hydraulic test pumps :
Max pressure: 500bar
Water flow: 40 lpm ~ 170 lpm
Engine: electric motor drive or diesel engine. Power: 30 kw~ 90 kw
Electric-powered: Typically used indoors because there are no fumes and they are quieter.
Diesel-powered: Self-contained and portable so they can be used in the field (no electric cords); all you need is water.
Main Features of the water pressure test pump electric pressure test pump China manufacture :
1.For the machine, pump is making with the tech. of Germany WOMA.
2.Small volume, bigger power, compact structure
3.Operates smoothly and suitable for long time continuous working.
Applications of the water pressure test pump electric pressure test pump China manufacture :
1.Pipe pressure test, hose pressure test, hydro pressure test, etc.
2.Shipyard rust removal, paint removal
3.Breweries yeast, sediments and fermentation residues on vats, pipe and facilities cleaning.
4.Aviation: expansion joints, grease, rubber and hydraulic fluid on runways cleaning.
5.hydropower station/ dam/dike concrete work treating.
6.Casting clean scale removal rust removal paint, removal sand.
7.Industrial pipe cleaning, such as starch factory, cement plant, etc…
Technical parameters:
speed of motor(r/min) | 1480 | Stroke(mm) | 95 | |||||||
Reduction ratio (i) | 3.65 | speed of pump (r/min) | 405 | |||||||
Power (KW) | 30 | 37 | 45 | 55 | 75 | 90 | Plunger diameter (mm) | |||
Rate Flow | Rate Pressure (Bar) | |||||||||
m3/h | L/min | |||||||||
2.4 | 40 | 370 | 460 |
|
|
|
| 22 | ||
3 | 50 | 300 | 360 | 450 |
|
|
| 25 | ||
3.42 | 57 | 260 | 320 | 400 | 500 |
|
| 26 | ||
3.9 | 65 | 230 | 280 | 350 | 450 |
|
| 28 | ||
4.5 | 75 | 200 | 250 | 300 | 380 | 500 |
| 30 | ||
5.1 | 85 | 170 | 220 | 260 | 340 | 450 | 500 | 32 | ||
6.12 | 102 | 150 | 180 | 220 | 280 | 360 | 430 | 35 | ||
8.1 | 135 | 110 | 140 | 170 | 210 | 280 | 330 | 40 | ||
10.2 | 170 | 90 | 110 | 140 | 170 | 240 | 280 | 45 | ||
This products could be made according to customer’s request.
If you would like more information, please do not hesitate to contact us . We will reply to you as soon as possible.
Contact information:
Name: Sarah
Skype: jycleaner1
Mobile: +86 15638115232
