Uhmwpe Mining Pipe Price

Specifications

Name:UHMWPE Mineing Pipe Price:

Q: What's the difference between HDPE pipe and UHMWPE pipe?

 A: the molecular wieght for HDPE pipe is only 30,000-50,000, however, the UHMWPE pipes is 3.5 million to 9.2 million. The higher molecular weight enables UHMWPE pipes to have a much better quality than HDPE pipes.

 Q: What's the advantages of UHMWPE pipes compared with HDPE pipes?

 A:   a) Wear Resistance: the wear resistance of UHMWPE material is the top among engineering plastics, It is 10 times better than HDPE material;

  b) Higher pressure bearing capability:  with 2 times better of tensile strength  than HDPE pipes, the UHMWPE pipes could bear higher  working pressure. In this case, with the same internal diameter, the UHMWPE pipes could have thinner wall thickness to bear same working pressure.

 Advantages of UHMWPE discharge pipe:

Longer Life

With a wear resistance 4 to 7 greater than Q235 Steel or 10 times that of HDPE (PE100) pipes under the same operating conditions, UHMWPE Pipe will give you far superior life under most operating conditions.

Lower Maintenance Costs, Less Maintenance Time, Less Downtime, Less Loss of Production

The far superior collaboration of wear resistance and weight reduction (0.93 SG) means the time between pipe replacements and/or rotations can be increased whilst simultaneously reducing installation management constraints of lifting gear and excavation requirements.

Reduced Pumping Costs

Along with the benefits mentioned above, UHMWPE Pipes also offer significant cost savings through increased pumping efficiency. With a surface roughness of 0.00022mm UHMWPE Pipe is extremely smooth and has resultant properties superior to PTFE (Teflon). Quantifying by example UHMWPE has a friction coefficient of 0.05, compared to 0.28 for HDPE or 0.58 for Steel (ISO 8295).

This means less friction, less pressure loss and greatly reduced energy inputs to deliver the same result.

Chemical and Corrosion Resistance

With chemical resistance second only to PTFE (Teflon), UHMWPE pipe will offer superior life to other pipeline products in acidic or corrosive applications under 85 degrees C.

Lower Installation Costs

The strength of UHMWPE pipes can offer many savings in installation costs:

• High compressive strength means reduced size or eliminating excavations (greater than 1.5x that of HDPE)
• Combination of strength and flexibility (>250% tensile elongation) means concrete bases are not required on wetlands and difficult terrain
• High strength and flexibility provides greater protection against damage due to ground subsidence, earthquakes or other unexpected movement and loading of the pipeline
• Can be laid directly on the seabed

Application of UHMWPE discharge pipes:

1. Dredging Industry: Floating dredge pipe for river channel/sea shore/lake/pond, sand suction/slurry dredge

2. Mining industry: mine powder, mine slurry, mine tailings, mine waste rock delivery

3. Sea engineering: Sea water desalinization, bunder dredging

4. Chemical industry: mud and corrosive medium with slag delivery

5. Gas & Oil Industry: Crud oil,petroleum and natural gas transport

UHMWPE pipes have been widely used in Mine Tailings Discharge, Sand & Slurry Dredging,  Chemical Industry, Gas & Oil field etc.

 UHMWPE Pipe Specifications:

 8'' Sand Mining Pipe Images:

About our company:

Q: What's the advantages of Shandong Buoy&Pipe Industry Co.,Ltd?

 A: a). Our company began to produce UHMWPE pipes since 2003, with 25 production lines, we have annual production capacity of 10,000 tons.

 b).Various Specifications: diameter ranging from I.D77mm to I.D1200mm. We are specialised in research and production of large diameter UHMWPE pipes.

c). Good quality: 100% virgin UHMWPE material is used, China material with 3.5 million,Ticona GUR 4120 and GUR4150  material also availabel for pipe production.

About our pipes:

Materials:

UHMWPE Pipe Production Lines:

UHMWPE Pipe Production:

Pipes Loading:

Quality Control:

 Certificate of our pipes:

Contact  with us:
