Door Frame Metal Detector

Walkthrough Metal Detector XYT2101-II

(6 detecting zones)

Technical parameter

Electric current: AC85V~264V/50-60HZ

Power: <20W, low consume, low radiation

Workplace environment: -20℃~+50℃

Standard: CE,ISO

Door panel size: 2230*560*82mm

Control unit case size: 700*380*180mm

Outer size:2234*835*580mm

Inner size:2000*700*500mm

Panel Material:Wood

Net weight: 65KG

The volume weight: 115Kgs

Packing:235*68*26cm,82*48*30cm

Volume: 0.65CBM

Characteristic & Function

• Ø  Program Self-diagnostic when power on, automatically checking left and right door panel, LED light and choose the best working frequency.
• Ø  Six mutual over-lapping detecting zones, Simultaneous alarm from multi- zones;
• Ø  Sensitivity adjustable: Each zone has 255 degree sensitivity level, three patterns: High, middle, Low for different requirements. Preset the metal size, weight, volume, location to exclude the coin, key, belt.
• Ø  Sound Alarm: 1-25s alarm time, 255 different sound volume for choose
• Ø  LED alarm: Six LED strip on the top control unit, indicate the alarm zones
• Ø  Automatically count passengers and alarm times
• Ø  Password protection, only the authorized person can operate.
• Ø  Easy assembly: designed with only 2 pieces cables and 8 screws, Simply-to-follow instruction.
• Ø  Harmless to human body: is harmless with heart peacemaker, pregnant women, magnetic floppy, recording tapes, etc.

Application

Walk Through Metal Detector XYT2101-II is designed for Exhibition center, Electronic Factory, Bank, Prison, Government office, Casino…etc
