Walk Through Security Gates,Door Frame Metal Detector

GUARD SPIRIT WALK THROUGH METAL DETECTOR
Model: XYT2101S (18 zones)

• Power Supply:AC85V-264V,DC 12V 3.5A
• Working temperature:-20℃--+50℃
• Working Frequency :4KHZ—8KHZ
• Standard External size: 2219mm(H)X898mm(W)X706mm(D)
• Standard Internal size: 2046mm(H)X750mm(W)X537mm(D)

Characteristic & Function

• Multi Zone-18 horizontal& Vertical zones of detection
• Target objects are independently detected and displayed in each zone for user’s easy recognition
• Self diagnostics& auto function for unskilled user’s convenience
• Frequency setting
• People& detection count function
• Sensitivity adjustment in each section(6channels),detection is available according to the size of metal objects
• 6 preset programs for application
• Easy-to-mount and easy-to-assemble
• Complies with international standard CE,ISO9001
• LCD screen and LED bar on both door frame
• Battery backup function (for customizing)
• Network support( for customizing)
• Password protection
• Operation with remote control for convenience

Learn More Function

• l  LCD screen with Infrared remoter controller,both Chinese & English program, easy to operate.
• l  Adopt advanced digital signal processing control replaced traditional analog signal control, better stability.
• l  Program Self-diagnostic when power on, automatically checking left and right door panel, LED light and choose the best working frequency.
• l  Detecting Zones: 6 detecting loops, can extend to 12,18 zones by separate left, right, middle side detection to pinpoint detection. Simultaneous alarm from multi- zones;
• l  Sensitivity adjustable: Each zone has 255 degree sensitivity level, three patterns: High, middle, Low for different requirements. Preset the metal size, weight, volume, location to exclude the coin, key, belt.
• l  Sound Alarm: 1-25s alarm time, 255 different sound volume for choose
• l  LED light alarm: LED bar graph on left and right door frame, visible alarm simultaneously to ascertain the layout of metal articles
• l  Password protection, only the authorized person can operate.
• l  Anti-interference function, using advanced interactive transmitting and receiving to avoid interference, frequency range from 4K-8K to avoid frequency interference
• l  6 preset programs for security application versatility
• l  Automatically count passengers and alarm times
• l  Microprocessor control on top unit, anti-interference and self-diagnose transmission channel to avoid internal and external interference.
• l  Easy assembly: designed with only 2 pieces cables and 8 screws, Simply-to-follow instruction.
• l  Harmless to human body: is harmless with heart pacemaker, pregnant women, magnetic floppy, recording tapes, etc.
• l  For option : Battery backup, 4 hours
• l  For option : Network support

Application

Airport, Banks, Embassies, Entertainment environments, factories, stores, Gymnasiums, Exhibition Centers for luxurious appearance

About Us

Our Company (Shenzhen Xinyuantong Electronics Co., Ltd., hereinafter “Company”) was established in 2000 with the registered capital of RMB 31.5 million, the total business space is 12,000 m2, there are more than 260 employees, including 120 research, engineering and technical personnel; we are one professional high-tech company which provides the solutions to the public safety, and provides the complete production and integration services.

The Company is committed to the technical development and research of “Guard Spirit” series of security products, the developed products have been granted by 28 national patents, and have formed five categories of products including the metal detectors, X-ray access security products, test products for radioactive materials, chassis inspection products, EOD and anti-explosion products.

Our Company has been committed in the business of access security, security equipments and services for 12 years, and during the period, we have provided safety and security services for hundreds of large-scale events, meetings, exhibitions, political and legal departments, railways, highways, ports and other places, including 26th Summer Universiade Shenzhen 2011, World Expo 2010 Shanghai, 16th Asian Games Guangzhou 2010, 14th FINA World Championship -Shanghai 2011, 24th Winter Universiade Harbin 2009, Olympic Games Beijing 2008, Wuhan-Guangzhou high-speed railway, Beijing-Shanghai high-speed railway and other key events and projects.
