Home > Products > Electronic Ballast > 2X36W T8 Electronic Ballast CE CB SAA
2X36W T8 Electronic Ballast CE CB SAA
US$ 4.92 - 7.5
/ Piece
300 Pieces(Min. Order)
- jiangmen guangzhou shenzhen
- T/T
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | OGJG | |
| Model Number | OG-E-(IC) | Style | Electronic | |
| Usage | Other, energy saving | Matched Tube | Other, t5/t8 | |
| Power Factor Compensation | Active |
Product Description
T8 Electronic ballast
Feature:
1.Certificate:TUV-CE TUV-CB SGS SAA EEI=A2 C-TICK A/12997EA
2.Environmental steel casing,scewless terminal block
3.Active high power factor correction, wide voltage input and constant power output.
4.Preheat start,long lamp life
5.Abnormal status self -protection function
6.Automatic shutdown of defective lamps(at the end of life)
7.Automatic restart of defective lamps
8.Low input voltage of repalcement lamps
9.Intelligently detect lamp type,one for multilamps
10.Suitable for use in emergency lighting systems
11.Wide ambient temperature: -10°C -+50°C
Specification:
| Model | Lamp | Voltage | System power | Power factor | THD | CF | Ambient Temp | Casing Temp | Hole sapcing | Dimensions |
| (mm) | (L*W*H)mm | |||||||||
| OG-E35(IC) | T5 1X35W | 110-240V | ≤38 | ≥0.99 | ≤8% | ≤1.3 | -10~50°C | 70°C | 350 | 360×25×22 |
| OG-E28(IC) | T5 1X28W | 110-240V | ≤31 | ≥0.99 | ≤8% | ≤1.3 | -10~50°C | 70°C | 350 | 360×25×22 |
| OG-E21(IC) | T5 1X21W | 110-240V | ≤23 | ≥0.99 | ≤8% | ≤1.3 | -10~50°C | 70°C | 350 | 360×25×22 |
| OG-E14(IC) | T5 1X14W | 110-240V | ≤16 | ≥0.99 | ≤8% | ≤1.3 | -10~50°C | 70°C | 350 | 360×25×22 |
| OG-E235(IC) | T5 2X35W | 110-240V | ≤74 | ≥0.99 | ≤8% | ≤1.5 | -10~50°C | 70°C | 350 | 360×30×28 |
| OG-E228(IC) | T5 2X28W | 110-240V | ≤60 | ≥0.99 | ≤8% | ≤1.5 | -10~50°C | 70°C | 350 | 360×30×28 |
| OG-E221(IC) | T5 2X21W | 110-240V | ≤45 | ≥0.99 | ≤8% | ≤1.5 | -10~50°C | 70°C | 350 | 360×30×28 |
| OG-E214(IC) | T5 2X14W | 110-240V | ≤31 | ≥0.99 | ≤8% | ≤1.5 | -10~50°C | 70°C | 350 | 360×30×28 |
| OG-E58(IC) | T8 1X58W | 110-240V | ≤61 | ≥0.99 | ≤8% | ≤1.3 | -10~50°C | 70°C | 350 | 360×25×22 |
| OG-E36(IC) | T8 1X36W | 110-240V | ≤39 | ≥0.99 | ≤8% | ≤1.3 | -10~50°C | 70°C | 350 | 360×25×22 |
| OG-E32(IC) | T8 1X32W | 110-240V | ≤34 | ≥0.99 | ≤8% | ≤1.3 | -10~50°C | 70°C | 350 | 360×25×22 |
| OG-E30(IC) | T8 1X30W | 110-240V | ≤32 | ≥0.99 | ≤8% | ≤1.3 | -10~50°C | 70°C | 350 | 360×25×22 |
| OG-E18(IC) | T8 1X18W | 110-240V | ≤20 | ≥0.99 | ≤8% | ≤1.3 | -10~50°C | 70°C | 350 | 360×25×22 |
| OG-E16(IC) | T8 1X16W | 110-240V | ≤18 | ≥0.99 | ≤8% | ≤1.3 | -10~50°C | 70°C | 350 | 360×25×22 |
| OG-E258(IC) | T8 2X58W | 110-240V | ≤116 | ≥0.99 | ≤8% | ≤1.5 | -10~50°C | 70°C | 419 | 429×30×28 |
| OG-E236(IC) | T8 2X36W | 110-240V | ≤76 | ≥0.99 | ≤8% | ≤1.5 | -10~50°C | 70°C | 350 | 360×30×28 |
| OG-E232(IC) | T8 2X32W | 110-240V | ≤68 | ≥0.99 | ≤8% | ≤1.5 | -10~50°C | 70°C | 350 | 360×30×28 |
| OG-E230(IC) | T8 2X30W | 110-240V | ≤64 | ≥0.99 | ≤8% | ≤1.5 | -10~50°C | 70°C | 350 | 360×30×28 |
| OG-E218(IC) | T8 2X18W | 110-240V | ≤39 | ≥0.99 | ≤8% | ≤1.5 | -10~50°C | 70°C | 350 | 360×30×28 |
| OG-E216(IC) | T8 2X16W | 110-240V | ≤35 | ≥0.99 | ≤8% | ≤1.5 | -10~50°C | 70°C | 350 | 360×30×28 |
Image:
Contact Us
- Jiangmen Ogjg Lighting And Electronic Co., Ltd.
- Contact nameCathy Ren Chat Now
- Phone86-750-3131535
- AddressPlant A, No. 4-5, Xincun 2nd Road, Sanya, Hetang Town, Jiangmen, Guangdong
