Brewery equipment/machine

* Capacity : 100L-10000L

* Material:Stainless steel 304

* Shell thickness :  > 2.5 mm

* Jacket thickness: >1.2 mm

* Outer shell thickness: >1.2 mm

* Shape : Sealing head top , 60°cone down

* Thermal insulation material : Polyurethane foam (PU) ,Insulation thickness : 50 mm or more .

* Accessories :

(1) Feeding hole & discharging hole,

(2) Temperature gauge with temperature probe & Pressure gauge ,

(3) Sampling valve & 360°cleaning ball ,

(4) Emptying hole & spare hole ,

(5) Manhole

(6) Leg which can adjustable , etc.

Fermentation Tank's vessel made of SUS 304 or 316L is designed to ferment and control fermentation process with mechanical blender.
Fermentation Tank are used to make such products as yeast, vitamin C, citric acid, penicillin, and other products. Fermentations are usually carried out in this vessel with multiple impeller systems. Air is sparged in at the bottom, to provide the micro-organisms with oxygen. It is important for the vessel that the mixer disperses the gas into fine bubbles, to ensure good mass transfer from the air to the product. It is equipped with automatic spray balls cleaning the vessel to meet the GMP requirements

  The Fermentation Tankcould even be designed in accordance with the requirements of customers.
