steel framed prefab modular housing

The Brife introduction of the Light Weight Fiber Cement Insulation Panel Prefab Home with solar panel:

- Layout: 2 bedrooms, 1 living room, 1 kitchen, 1 dining room, 1 washing room, 1 porch and 1 terraces.

- Installation speed: 3 working days (5-8 labors)

- Including: as pictures showed below

- Package: standard sea freight package

- Shipping: by sea, 1*40 HQ

- this design also suit for higher standard villa system

1. Steel structure:

* The steel structure is galvanized with very good antirust effect.

* All the steel structure sections are made in factory, there need no cuting, no welding work, all the sections are prefabricated.

* The strong steel structure technical data:

The wind-loading is 120km/h - 180km/h wind,

The roofing loading can be reached to 700 kg/square meter.

The anti-seismic intensity is 9 on the Richter scale.

2. Wall panel & roofing panel:

* The wall panel is a composite panel with a new concept.

* It combines with the advantages of both the good insulation of the EPS (formed cement as advaced option) and the strength of the reinforced concrete.

* The technical tada of the cement insolation sandwich panel:

light, the weight is 15kg/square meter - 25kg/square meter, it is about 1/20 of the traditional wall.

thermal conductivity: W/(m.k): 0.026~0.035

working tempreture: -260℃~900℃

fireprrof: A grade, Non-combustible

sound proof: 45dB

3. Flooring (single floor without flooring suporting system)

* The floor structure is "C" purlin or "Z" purlin with the steel structure.

* The floor panel is cement panel. You can block the flooring very fast.

* All the items are prefabricated in the factory and mark the number on each one. You can install them by the technical drawing offered by us.

* After the panel work, there need only few cement work full into the joints then flat it.

4. Interior finishing

* The floor is ceramic tile (composite wooden floor is optional).

* The wall is white painting.

* The ceiling is gypsum panel (office with Aluminum stay & for home is flat white ceiling
