JINKA RD2010-4 CNC router round and platform engraving
- Shanghai/Other port as customer request
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
JINKA RD2512-2Z-8 CNC router round and platform engraving
-
JINKA RD2510 CNC router round and platform engraving
-
JINKA RD5010-2Z-8 CNC router round and platform engraving
-
JINKA RD6590 CNC router round and platform engraving
-
JINKA RD3020 CNC router round and platform engraving
-
JINKA RD3010-6 CNC router round and platform engraving
Product Details
Condition | New | Place of Origin | Anhui, China | |
Brand Name | JINKA ZIXU | Model Number | RD 2010-4 | |
Rated Power | 0.8-2.2KW | Engraving Speed | 20m/min | |
Main Axle Rotational Speed | 6000-24000rpm/min | Feeding Height | 300mm | |
Milling Cutter Diameter | 3.175/4/6mm | Application | Metal Materials,stone,plastic,jade,others,aluminum,brass | |
Dimensions | 3000*3000mm | Weight | 2000kgs | |
Certification | ROHS,CE,BV,ISO | Warranty | 1Year | |
After-sales Service Provided | Overseas service center available |
Product Description
JINKA CNC Router/engraving /MINI desktop mould cutting machine for metal working lower price higher quality
Character features:
1.Imported linear guideway to ensure heavy loading, stable running and high precision
2.Gear rack transmission for Y-axes and ballscrew for X, Z axixes to ensure high accuracy and abrasion resistence
3.Automatic lubrication system for option to save maintenance time and to extend the lifetime of linear guideway
4.Constant power water-cooling V/F spindle and well-performed inverter to make sure high torque and high efficiency
5.Fast and stable by adopting brand hybrid servo motor and drive, and double motors for Y axis
6.Recovery function by remembering the working coordinate and continue to work with it after cutting of power and braking of tools;
7.Compatible with any advanced CAM software, such as Type3/Artcam/CAXA/UG/Pro-E/Mastercam/Ucancam and so on
Model | RD-2010-4 |
Cylinder Length | 1000mm |
Cylinder Diameter | ≤200mm |
Idle Speed | 20m/min |
Processing speed | 15m/min |
Spindle power | 800W-2.2KW Water-cooling |
Spindle speed | 6000~24000 rpm/min |
voltage | AC380V/50Hz |
tools | 3.175/4/6mm |
file format | G-code/HPGL |
resolution | ±0.03mm |
presicion | ±0.02mm |
Control system | NC Studio |
Application field:
European-style marble pillar; Archaized blackwood furniture; Pencil vase; Brush pen; Chopsticks; Bamboo Handicrafts; Tridimensional handicrafts; Jewelry; any otjer cylindrical objects.
Optional Configuration: | |
Z axis | Single Z axis/Double Z axis |
Spindle Power | 800W/ 1.5KW/2.2KW/3/5.5KW |
Spindle Brand | LINNAN/HANQI/SHANGKE/HSD |
Spindle Specification | General/Lengthened/Constant Torque |
Spindle Type | Water-cooling/Air-Cooling |
Control System | Nc Studio/Nc Studio(advanced)/DSP/Four-axis-three linkage+ handle |
Servo system | Panasonic/Yaskawa/Domestic Servo/Leadshine |
Stepping Motor | Leadshine/CW |
Industrial cooling | Water cooling /Oil cooling |
Dividing Head | |
Handwheel |
Hefei Kaxing Digital Control Equipment Co.,Ltd is a high-tech industry enterprise intergrating research,development,manufacturing,sale and after-sales service.We are able to offer preminum quality products an affordable price because we are a factory direct manufacture may offer similar products.We pride our-selves in not only our professional;and strict product line but also incredible custmer service & technical support.
1,There being a core manufacture specialized in Vinyl Cutter and CNC Router for more than 10 years;
2,CE,RoHS,,ECM,STQ certificated;
3,Strictly checking and controlling quality;
4,More than 60 distributors in domestic and international market;
5,Short delivery time(7~20 days);
6,The Core Competitiveness of product price;
7,Professional sale and aftersales
8,replying your any inquiry within 24 hours
We hope to build a deep and long-term cooperation with you as your any needs.
1.How could I get more informations from you?
You could send email,fax or phone us,told us what informations you want(such as air/sea freight,prices and so on),we will reply you in time,then you will know better about our CNC machine and service.
2.Why we have to buy cutting plotter from you?
We are one of the largest and best manufacture of CNC machine in China. We have many year's experience in producing CNC machine equipments,the quality and prices of our machines/materials are superior to others.
And we have specialized marketing group and technical team, we could provide the best service,advice to you.
3.How can I receive your goods?
If you order little quantities(below 100KG)you could use DHL,TNT,UPS or other air express company to delivery your goods,delivery time usually 3-4 working days,they will send the products to your address.
If you order large quantities,you could use sea delivery,and you need to go to your nearest seaport to take your goods,delivery time usually 30-40days.For more details,please contact with us.
4.Way of payment.
We accept the T/T,Western Union,paypal. When we receive your payment,we will prepare your goods and send to you in time. If you order large quantities,you could pay 30% deposit to us,when all the goods ready,we will take photos for you to check it.For more details,please contact with us.
5.How become your sole agent?
When you reach our request quantities,you could become our CNC machine sole agent in your country.
For more details, please contact with us.
