TENA 5mm (Model:TN-TPG-5) Tempered Glass

Scientific principle

Tempered glass, also known as toughened or reinforced glass, is made by annealed glass heated to its softening point and quickly cooled by air flow on the surface. After the tempering process, an uniform compression is formed over the glass surface while tensile stress formed inside the glass sheet. Thus both its mechanical strength & heat-stability are increased greatly compared to common glass sheet.

Superior safety

In case of being broken, TENA tempered glass sheet will change into thousands of tiny pieces without acute angles. Thus no injuries to the body of human beings can be caused. As shown by the two photos below.

                 Broken tempered glass                                               Broken common glass

High-impact performance

TENA tempered glass can withstand the vertical hit of a 1 Kg steel ball falling freely from 1 meter height, and separately, the side hit by a 45 Kg ball of lead bullets from 1.2 meter height, without broken. Its performance is 5~10 times higher than that of ordinary flat glass sheets.

Better heat-stability

It can stand a heat-shock (sudden change of temperature) of 220~250 °C, while a common glass sheet of the same thickness can only stand 70~100 °C.

Types of single sheet

Clear transparent, tinted, colorful glazed, film coated, Low-E, etc.

Types of combined sheets

Laminated, insulated, etc.

Test Reports

Passed test of National Standard < GB 15763.2-2005, Safety glazing materials in building-Part 2: tempered glass>

Applications

TENA tempered glass sheet is a kind of safety glass meeting both high mechanical and safety requirements. Can be used on external/internal curtain walls, doors & windows, elevators, partitions, atrium, lighting roof, and other locations in buildings, such as hotel, shopping mall, museum, concert hall, theater, business center, airport, library, university, CBD area, banks, media center, hospital, apartments, etc. And can be used in furniture and home appliances as well.

Building projects applied

TENA products have been widely used successfully in hundreds of outstanding buildings, such as National Center for the Performing Arts (NCPA) in Beijing, Guangzhou International Finance Centre (IFC), Guangzhou Railway Station, 5-star Sheraton Dameisha Resort Hotel Shenzhen,etc. TENA products are winning the trust of more and more clients.
