TENA (Model: TN-LG-6638) Laminated Glass

Description & scientific principle

TENA laminated glass is composed of 2 or more tempered glass sheets & interlayer films. It is very difficult to breakthrough the laminated glass by force because combination of the strong, durable tempered glass & interlayer films can absorb and lessens quickly most of the shocking energy. Even if the outer glass sheet is broken by hard force (eg. a heavy steel hammer), the debris can be kept still by strong adhesion of the interlayer to avoid hurting people or valued articles nearby.

      Structure of laminated glass        Broken laminated glass               Broken common glass

Superior safety

In short, TENA laminated glass is a kind of excellent safety glass with 3-High Performances, that is, High mechanical strength, High tenacity, and High adhesion. The characteristics allow the glass to be applied in most locations in a building.  As the glass sheets are tempered glass, the safety performance is further strengthened.

High-impact performance

TENA laminated glass can withstand the vertical hit of a 1 Kg steel ball falling freely from 4.8 meter height, and separately, the side hit by a 45 Kg ball of lead bullets from 1.2 meter height, without producing broken debris or scattering broken debris, and the interlays remain unbroken in all these tests.

Energy saving

It can reduce remarkably the heat transmission between inner and outer space. Hence it can help cut energy consumption of air-conditioners and save the cost of using power.

Noise reduction

It can act as the doors & windows of a building and block the noise from outside notably.

Blocking UV

It can block a large percentage of UV from sunlight. This property can help reduce the harmful UV to avoid color-fading of furniture, articles and valuables inside the room.

Test Reports

Passed test of National Standard < GB 15763.3-2009, Safety glazing materials in building-Part 3: laminated glass>

Applications

TENA laminated glass sheet is a kind of safety glass meeting both high mechanical and safety requirements. Can be used on external/internal curtain walls, doors & windows, elevators, partitions, fences, atrium, lighting roof, doorway, bathroom, show windows, show cases, and other locations in buildings, such as hotel, shopping mall, museum, concert hall, theater, business center, airport, metro lines, library, university, CBD area, banks, media center, hospital, apartments, etc.

Building projects applied

TENA products have been widely used successfully in hundreds of outstanding buildings, such as National Center for the Performing Arts (NCPA) in Beijing, Guangzhou International Finance Centre (IFC), Guangzhou Railway Station, 5-star Sheraton Dameisha Resort Hotel Shenzhen,etc.
