GKHS-35E 35M Composite Boom (DONGFENG) Aerial Working Platform
- shanghai
- T/T
You May Like
Product Details
| Place of Origin | Heilongjiang, China | Brand Name | LIONKIN | |
| Model Number | GKHS-35E 35M |
Product Description
Specifications
Automatic-leveling platform,Hydraulic platform rotation, 360 continuous turntable rotation,Fully proportional joystick controlsMain Parameters | ||
Bulletin No. | KFM5160JGK407H | |
Type | GKHS-35E | |
External dimensions | 11245×2490×3700 mm | |
Structure type | Four-section telescopic boom & One-section articulated boom | |
Working Cage | Internal size | 2000×700 mm |
Rated loading | 320 kg | |
Max. Working height | 35000 mm | |
Max. Height from ground | 33300 mm | |
Max. Working radius | 24000 mm | |
Working radius when doing the highest height | 5900 mm | |
Working Boom | Max. Raising angle of lower boom | 80 º |
Max. Raising angle of jib | 90 º | |
Boom rack rotation angle | 360 º | |
Outrigger | Vertical span | 5300 mm |
Horizontal span | 4780 mm | |
Traveling of vertical outrigger | 650 mm | |
Adjustment | Single adjustable | |
Chassis Introduction | ||
Traveling | Chassis model | DONGFENG DFL5160XXYBX1A |
Performance | Persons | 3 |
Parameters | Axle base | 5000 mm |
Wheel base (front/rear) | 1880/1800 mm | |
Driving mode | 4×2 | |
Front suspension | 1430 mm | |
Rear suspension | 2440 mm | |
Approaching angle | 20 º | |
Departure angle | 13 º | |
Min. Turning diameter | 19000 mm | |
Min. Ground clearance | 248 mm | |
Engine | Engine model | ISDe210 40 |
Rated power | 155 kw | |
Max. Speed | 90 km/h | |
Specification of the tire | 10.00-20 | |
The whole weight | 15805 kg | |
Max. Weight with whole loading | 16000 kg | |
