FLB468A Backhoe Loader

Parameter Items

Parameter Value

Gearbox type

CARRARO Hydraulic gear-shift double variable

Gear

Forward IV reverse IV

Gear I forward(km/h)

5.8

Gear II forward(km/h)

10.5

Gear III forward(km/h)

20.1

Gear VI forward(km/h)

36

Gear I Reverse(km/h)

5.8

Gear II Reverse(km/h)

10.5

Gear III Reverse(km/h)

20.1

Gear VI Reverse(km/h)

36

Specification of front tyre

14-17.5-14PR/11L-16-12PR

Specification of rear tyre

19.5L-24-12PR

Pressure of front wheel(Mpa)

0.55/0.44

Pressure of rear wheel(Mpa)

0.23

Steering system

Type

Full-hydraulic steering

Turning angle(.)

45

Minimum turning radius(mm)

4370

Hydraulic system

System work pressure(Mpa)

21

Raising time(s)

3.4

Total time(s)

8.8

Brake system

Operation brake

Wet brake

Parking brake

Flexible shaft wet brake

Fuel-filling capacity

Fuel tank(L)

130

Hydraulic tank(L)

180

Performance parameter

Operating weight (kg)

8300

Standard bucket capacity (m³)

1

Rated load (kg)

1700

Maximum traction force (kN)

58

Maximum creeping capacity

30

Maximum dumping height (mm)

2665

Dumping reach(mm)

788

Rated bucket capacity (m3)

0.18

Maximum dumping height

3450

Maximum digging depth (mm)

4135

Maximum digging reach(mm

5310

Outer size(L×W×H mm)

5900×2320×3510

Engine

Model

Tianjin Perkins 1004-4TEL04

Type

Vertical in-line, four-cylinder, water-cooling, four-stroke, vertical-spray

Number of Cylinders-cylinder diameter× stroke (mm)

4-100×127

Maximum torque (Nm)

370

Rated power (kW)

68.5

Rated speed (rpm)

2200

transmission system

Torque converter type

CARRARO Single-level, single direction and double-variable
