Home > Products > Plastic Bucket Printer > DAKE-350T Plastic Bucket Offset Printing Machine With UV Curing
DAKE-350T Plastic Bucket Offset Printing Machine With UV Curing
- Shanghai
 - T/T

You May Like
Product Details
| Condition | New | Plate Type | Letterpress | |
| Place of Origin | Shanghai, China | Brand Name | DAKE | |
| Model Number | Dake-350T | Usage | Other, plastic bucket printer | |
| Automatic Grade | Automatic | Voltage | 380V | |
| Gross Power | 25KW | Dimensions(L*W*H) | 5m*4m*3m | |
| Weight | 8000kg | Certification | ISO9001:2000 | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Main Features:
1. Offset plastic bucket printing machine
2. ISO9001
3. Flame treatment before printing
4. UV curing after printing
5. Very quick change over of mandrels and printing plates
6. Layer printing effects & photographic printing quality
I. Dake-350 plastic bucket offset printing machine
1. Use
Model DAKE-350T Automatic Plastic Bucket Printer is used for printing plastic bucket which is six colors.
2. Characteristic
a. Very quick change over of mandrels
b. Automatic equip UV on-mandrel curing system
c. Controlled by frequency conveniently and quickly
d. Checking accurately, conveniently and quickly
e. Control and error check
f.  Layer printing effects & photographic printing quality
g. Flame treatment before printing
h. Color station opening structure
3. Main technical parameters of the equipment
Model Number: Dake-350T
Total power: 25KW
Air consumption: 0.5m³/min
Colors: 6
Diameter of barrel rim: 125mm~ 400mm
Max Height of barrel: 400mm
Taper degree of barrel: 2°~10°
Max printing square: dia350mm*300mm
Fastest printing:  dia125mm~ 200mm, 135pcs/min;
dia200mm~ 400mm, 45pcs/min
Drying method: UV curing
Size of machine: 5m*4m*3m
Total weight: 8000kg
4. Samples
II. Printing process

III . Main parts of the bucket printing machine
1. Printing mandrel & UV curing lamp
2.  Siemens control panel

1. For each new printer, Guarantee Period: one year
2. For each new printer, we provide one set of mould (printing mandrels) for free.
3. After-sales service provided: Engineers available to service machinery overseas. We will arrange professional technician to go to your company for machine installating, debugging and provide free technical training.
4. If you send us the image (format is CRD or AI) that you want to print on the bucket, we can process the image, make the prinitng plate and print bucket samples for you for free.
5. When you visit our factory for product acceptance, we can teach you how to make the plate on the computer with software CorelDRAW for free.
Shanghai Dake Machinery Co., Ltd. is located in Shanghai of China. We are professional manufacturer for 16 years. Our main products are bent offset printing machine series for plastic cups, bowls, barrels and tubes, and plastic cup coiling machines.
DAKE integrates development, production, sales and service as a whole. We preserve the operation tenet of "survive on quality, develop on innovation and win credit on consummate service", and we pay much attention to clients' requirements. We hold market trends timely, keeping improving the quality of our products continuously, developing new products and improving service quality insistently. Our products are sold all over China and exported to Southeast Asia, Europe, America and other countries and areas. With a high credit standing in both domestic and overseas markets, our company and products have won lots of favors from vast new and old clients.
DAKE is great. Through the unremitting diligent work, DAKE has invented the first plastic coiling machine in China. Now the new coiling machine reaches a high output of 1,000,000 cups one day.
Our philosophy is that what we sell is not necessarily the best, but the most suitable for you.
1. Q: Are you a factory or a trading company?
A: We are a factory for 16 years, specializing in offset printing machines for plastic cups, bowls, tubes, buckets and plastic cup coiling machine. Welcome to visit our factory.
2. Q: What are the main markets of your company?
A: Our products are sold all over China and exported to Southeast Asia, Europe, America and other countries and areas. With a high credit standing in both domestic and overseas markets, our company and products have won lots of favors from vast new and old clients.
3. Q: Can we see how your machine work in your factory?
A: Yes, welcome to visit our factory, we will show you how to operate the printer. And we have client who bought our offset printer and his factory is only 5 minutes' drive from our company.
4. Q: Can we send you buckets to print so we can check the printing quality?
A: Yes, if you send us the original designing draft (format is CRD or AI) that you want to print on the buckets,
we can process the image, make the prinitng plate and print bucket samples for you for free.
5. Q: What about the delivery?
A: Delivery time is 2 months after we received the advance payment, but the delivery will change based on our production situation.
