Warm White/nature White/cool White LED Tube Lighting,LED Tube Light,LED Cabinet Light T8 T5

 FEATURES:

Shell: Aluminum alloy shell, with transparent PC, strip PC and  frosted milky-colored PC to choose;

Light Source: SMD3014/2835 LED is made of high bright chip produced in Taiwan, packaged in low attenuation technique. Luminous flux of single LED reaches 6.5-7.1  lm, no attenuation  after 3000 hour test, comply with  LED lumination standard.

Power Supply: Independently developed constant current device, with over-current, over-voltage, over-heat and surge protection.

Certificate: CE, RoHS

More type:

SPECIFACATION:

l High brightness:used 2835/3014 SMD LED

l Easily Installation: Unused  Ballast and Starter device

l Long lifespan: Up to 30000 hours

l Weatherability: and is not sensitive to humidity. The same temperature range to adapt to a greate

l Saving electricity

l Environmental protection, there is no heavy metals and harmful gases

l No strobe, for the protection of a great vision.

Picture:

Installation:

1.Open the package, examine the products carefully to see if there is any damage, if there is damage, do not attempt to use it;

2.Input voltage must be in line with the request;

3.Remove the ballast;

4.Before install the tube, make sure to switch off the power;

5.Take off the label from the tube;

6.Install the tube in accordance with the above CIRCUIT DIAGRAM, make sure the live wire enters switch, zero lines enter lamp holder;

7.Do not use sharp tools in case scratch the tube;

8.Lights installed;

9.LED tube can work 8 hours everyday. Do not use it more than 12 hours per day;

10.If you have any question, please contact our customer services.

Circuit Diagram:

SCOPE OF APPLICATION:

SMD LED Tube is applicable to interior illumination in various occasions, such as assembly line, workshop, office, home, supermarket, school, hospital, parking lot and so on. It also can be used in the lighting box and illumination for the places where is not easy to replace or maintain.

Notes:

Examine the product carefully after open the package. If the product were damaged in transportation,please notify us immediately; do not use the damaged lights.

This LED tube has two voltage input mode, one is AC220-AC250V, and the other is AC100-AC120V. Firstly, confirm the suitable voltage. Then remove the ballast because LED tube does not need it, otherwise it will cause short circuit. Next, connect the pins of one side with live wire, and the other side with zero line. Do not connect the live wire and zero line with the pins in one side, otherwise it will cause short circuit.

1. Shipping by EMS, DHL, UPS, FedEx, sea shipping and air shipping according to customers' requirement;

2. Normal delivery time: 7-10 working days.

Packing: standard carton

1. Competitive price;

2. Our products are under strcit quality control ;

3. Large producing capacity : 80,000pcs/month;

4. Any quantion willbe replied as soon as possible.

5. Professional LED light supplier with more than five years experience;

5. Your private information will be well  protected.

We accept T/T(in advance), Paypal, Western Union.

Q: 1. Can I have a sample order?

      A: Yes, welcome sample order to test and check quality.

Q: 2. Do you accept OEM /ODM services?

      A:  Yes, we accept and produce as your requests .

Q: 3. Which payments are acceptable?

      A: PayPal, Western Union, T/T all are acceptable.

Q: 4. Which shipping methods are available?

      A: Sea,. Fedex, DHL,  UPS, EMS, BY ARI(door to door) all are available.

Q: 5. How about the lead time and delivery time of my order?

      A:  Normal lead time is 3-7days according the detail order.

Q: 6. How to order ?

      A: Pls contact us online or send us email, we will send you PI, once receiving your payment, we will arrange produce your goods.

Q: 7. How about the Online shop?

      A: Yes, you also could order online directly on our official shop.

Q: 8. How to proceed the order if I have logo to print?

  A:1) send us the logo files, once receiving your payment, we will arrange to design the logo;

     2) after received your confirmation of the logo, we will do sample and send it to you check;

     3) if you confirm the sample is ok, we will produce the mass;

     4) once ready, pls pay the rest payment and we will produce goods and arrange shipment

Q: 9. What is the guarantee of our products and how about the returns?

  A:1) Two year warranty,According the goods quality,and we give different warranty time

     2) Warranty service will be honored if the damage is not caused by human;

     3) Pls send back the defective goods within the warranty period, we will repaire them or send you new free;

     4) If there are only several pcs accessoires(the fee is less or around shipping fee) are damaged,

      pls send us some pictures and video about the detail problem. Once confirmed the problem,

      we will send you free new goods instead with your next order.

Q: 10. Do you accept drop shipping?

     A: Yes, it's available, we will send out goods according your detail shipping address.

If you have any questions, Please do not hesitate to contact me!
