YEMOO DJ Series Heat Exchanger Evaporator High Quality Industrial Evaporator for Food Storage

Evaporative Air Cooler/Air cooled Evaporator For Cold Room

DL DD DJ series for your choice

DL : High temperature

DD : Medium temperature

DJ : Low temperature

Characteristics

 1.Scientific structure heat exchanger evaporator, high efficient, frost steadily, save power and low running cost;

 2.Heat exchanger evaporator is equipped with axial fan quiet models that offer strong air flow in long shot rang; save power, long service life;

 3.Copper pipe thickness can reach to 0.6mm, which lead to perfect tightness between pipe and fin after expansion processing;

 4.Heat exchanger evaporator is equipped with stainless electric heater in high insulating property, defrost efficiently in shot time;

 5.The heat exchanging coil was did gas tightness test under 2.6MPa air pressure, to guarantee quality.

 6.Aluminum and painted stain board, to meet your different needs.

Sphere of application

High temperature type: (cold room temperature 12~-2^oC)fin space:4.5mm;

Medium temperature type: (cold room temperature-2~-10 ^oC) fin space:6.0mm;

Low temperature type: (cold room temperature-10~-31 ^oC)fin space:9.0mm;

Attention of model selection

When the cold-room temperature is aroud 0 ^oC, select 8 ^oC to be the difference between compressor evaporating temperature and cold-room temperature.

when the cold-room temperature is aroud -18 ^oC select 7 ^oC to be the difference between compressor evaporating temperature and cold-room temperature.

when the cold-room temperature is aroud -25 ^oC, select 6 ^oC to be the difference between compressor evaporating temperature and cold-room temperature.

1.We are Professional factory to make semi-hermetic compressor and condensing unit more than 10 years.

2.We insist on innovation,purchasing the international quality materials,strong  technique  support,strictly control the production.

3.We firmly believe quality first,perfect production responsibility system.

4.We promise all Yemoo brand products,we supply 3 months new products guarantee replacement,12 months quality guarantee service.

So,what Yemoo can support you ? It's best price ratio products,perfect after-sales service guarantee.

Yemoo's value is what we supply you is not only products,but also creating you most value.
