300-500w portable solar system

Product  Features

Suitable  Places

AC 220V-110V OUTPUT

All areas without electric power supply

12V DC OUTPUT

where power cut happens often

Charging and discharging status shown by LCD display

Field work or suburb temporary office

Input, output with safety protection function

In Island and fishing

Easy machine operation and mounting installation

Border post, nomad tents

Particular charge controller keep the batteries regulated  with high efficiency and longer running hours

Night market business

Moderate  weight and easy to carry

Sight spot

Model

G101

AC voltage

AC220V±5%    One connector

Rated  power

300W

500W

Surge  power

450W

750W

Wave and frequency

Modified wave 50HZ±1%

Pure wave 50HZ

Modified wave 50HZ

Pure wave 50HZ

DC output

DC12V10A          DC output Terminal

Charging voltage

17.2V

Charging input mode

Terminal

Main machine shell

zine coated and anti-corrosin steel

Display Type

LED display working status of charging and discharging and battery

Solar charger controller

10A/12V Solar charger controller

20A/12V Solar charger controller

Battery

Solar gel or Lead-acid battery12V (According to need to increase or decrease)

Solar panel wattage

According to need to increase or decrease

Environment

relative humidity:-20 ºC ~60ºC               relative humidity:95%

dimension of machine

245X130X110mm

dimension of packaging

300X170X130mm

Machine net weight

2.5Kg  (without  battery)

Elevation limit

<6000m

Other

Electric power generated    W/day

540W(90W Panel)

Capacity of electric power storage W

960W(80Ah/12V)

Appliance equipment

Running Hours

3W DC LED lamp            5P

45h

11W Efficient lightbulb        5P

12h

21-inch TV                 80W

8.5h

Fan                       40W

17h
