Wide leg setable electric stacker battery charger forklift

FOB Price

USD $4,000 - $6,500 / Set

1 Set(Min. Order)

Port SHANGHAI
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Jiangsu, China
Brand Name	Jetstar	Model Number	CTD2055
Type	Powered Pallet Truck	Power Souce	AC Motor
Rated Loading Capacity	2000kg	Max. Lifting Height	5500mm
Min. Lifting Height	90mm	Fork Length	1150mm
Fork Width	320mm	Overall Dimensions	17258701965mm
Certification	CE ISO	After-sales Service Provided	Overseas third-party support available

Product Description

Wide leg setable electric stacker battery charger forklift

Product Description

Wide leg setable electric stacker battery charger forklift

Wide leg setable electric stacker battery charger forklifts are designed to operate in narrow passage and limited space and are ideal facilities to load/unload and stack goods in stacking warehouses, suoermarket and workshop etc. these trucks can be moved and operated easily and swiftly, with similar function to the electric stackers.

Technical Data

General	Model		Unit	HL15
	Rated load capacity		kg	2000
	Power			Tractive-type battery
	Operator type			Pedestrian / rider (pedal)
Characteristics	Maximum lifting height		mm	5500
	Lowered height of fork		mm	≤90
	Minimum turning radius		mm	1650
	Minimum aisle width		mm	2800
	Minimum ground clearance		mm	30
	Standard fork length		mm	1150
	Standard fork width		mm	175
	Fork overall width		mm	570
	Fork individual width		mm	220
Chassis	Overall length		mm	1988
	Overall width		mm	1000
	Mast extended height		mm	5940
	Mast lowered height		mm	2485
Performance	Maximum traveling speed	Laden	km/h	4
		Unladen	km/h	6
	Maximum lifting speed	Laden	mm/h	80
		Unladen	mm/h	130
	Maximum lowering speed	Laden	mm/h	110
		Unladen	mm/h	90
	Gradeability	Laden	%	5
		Unladen	%	8
Brake	Braking type			Electromagnetic
Wheel	Wheel type front/rear			Poly/Poly
	Wheels			1×Driven wheel,2×Balance wheel,4×Front wheel
	Balance wheel dimension		mm	Φ156×75
	Axis space		mm	1450
Motor	Driving motor		kw	1.2
	Lifting motor		kw	2.2
Battery	Battery(Voltage/Capacity)		V/Ah	24/210
Control	Control system			Curtis I207a
Weight	Weight		kg	1380

this specifications only for reference,we also suppose customized,tell me the requirements you need, our professional engineers will try their best to design them until you feel satisfied.
