17W Immersion UV Lamp Sterilizer

Immersion UV lamp sterilizer

Introduction:

Using 304 or 316L stainless stell material made of pipeline reaction cavity (inside and outside carry on high strength polishing processing), the UV lamp installed in the high transmittance quartz sleeve, sealed by the 0-type circle. Water flows inlet meanwhile the ballasts light UV lamp, high intensity irradiation of UV kill the bacteria and viruses in water, the sterilization rate can reach 99.9% when the water flow out.

Features:

System design criteria used by the U.S. NSF55, and CJ/T204-2000.

Product specification is complete, flow range from 0.1 to 500T/Hr.

Immersion connector using special food grade PTFE, resistance to ozone and UV aging, easy installation, sealing strong.

Low-pressure high-intensity mercury lamp, life of 9000-13000 hoours, supporting high-efficiency electronic ballast, sterilizaton rate as high as 99.99%.

Application:

The 254nm UV lamp for double seal with high transmittance quartz sleeve and the connector of our company die sinking produced, install it in the water tank directly, to kill the bacteria in the water and air of the tank, effectively prevent inhibit bacteria breeding and prevent secondary pollution of water in the tank, and into the water directly, the material is water proof IP68.

Specification

Remarks:

1. Below 75W UV sterilizer used for diameter <1M tank sterilization.

2. >1M tank must use one or combined units of 120W or 150W sterilizers.

3. Above specifications are valid for 15 days.

UV tank used for swimming pool system

***********************************************************

Packaging

A) Inner layer: plastic bag

B) Middle layer: EPE(Expand aple poly ephylene)

C) Outer Layer: carton/composite wooden cases

Prompt delivery

1. 3-7 days for portable ozone generator order;

2. 10-30 days for industrial/middle size ozone generator order.

Payment terms

***********************************************************

About US

WHAT WE DO?

We Provide high-quality UV tank for:

UV tank wholesalers

Retailers and oneline shops (Ebay, Amazon...)

OEM-The custom-made UV tank are available. Upon customer's idea, drawings, photos etc.

ODM-The modification of the UV tank after customer's selection is accepted.

Excellent after-sales service:

1 year warranty again the manufacture defect, offer life time consultation on problems occurred.

Report on the making process.

Marketing feedbacks tracing.

***********************************************************

All of our products are favored and trusted by customers with contemporary design (simplicity, innovation, practicability, multifunction and fashion), convenient operate, durable and its competitive price.

Please don't hesitate to contact with us, you are strongly expecting and welcoming to be the one of our partners in the coming day!

***********************************************************
