600W/800W/1200W/1600W wind turbine

FOB Price

US$ 345 - 738 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	NEWSKY
Model Number	MINI400W-5PLUS		Type	Wind Power Generator

600W/800W/1200W/1600W wind turbine
Bearing from "SKF"
Partner of F.A.O
3years warranty
CE,Rohs

Product Description

Feature of 600W/800W/1200W/1600W wind turbine

SPEC of 600W/800W/1200W/1600W wind turbine

Model	MAX 600W	MAX 800W	MAX 1200W	MAX 1600W
Rated power	600W	800W	1200W	1600W
Max power	750W	950W	1300W	1800W
Rated voltage	24 VDC	48 VDC	48VDC/110VDC	48VDC/110VDC
Rated current	25A	16.7A	25A/10.9A	33A/14.5A
Rated Rpm	650
Rated wind speed	12m/s
Blades	5 Pcs Nylon Fiber glass
Start-Up Wind Speed	1.5 ( m/s)	1.5 ( m/s)	2.0 ( m/s)	2.0 ( m/s)
Cut-In Wind Speed	2.0 (m/s)	2.0 (m/s)	2.5 (m/s)	2.5 (m.s)
Rotor Diameter	1.7 m	1.8 m	2.0 m	2.2 m
N.W	28.5KG	30KG	36KG	41KG
G.W	33KG	35.5KG	41KG	46KG
Shipping Dimensions	1690540290mm	1690540290mm	1890540290mm	1890540290mm
Mount	Flange connection
Turbine Controller	MPPT wind solar hybrid controller
Body	Cast aluminum
Overspeed Protection	Electromagnetic & blade aerodynamic braking
Working temperature	—40°C~ 150°C
Certificate	ISO9001:2008 ,CE, Rohs
Survival Wind Speed	50 m/s
Warranty	3 year limited warranty

Dimension of 600W/800W/1200W/1600W wind turbine
