Expanded Metal Mesh
- xingang
- T/T
You May Like
Product Details
| Place of Origin | China | Material | Stainless Steel Wire | |
| Type | Expanded Mesh | Application | Protecting Mesh | |
| Weave Style | Plain Weave | Wire Diameter | 0.3-8.0mm | |
| Technique | Perforated | Model Number | XQY-E-001 | |
| Brand Name | XQY |
Product Description
Specifications
Expanded Metal Mesh1.Expanded Metal Mesh
2.Thickness:0.4-8mm
3.Strip:0.5-5mm
4.Opening width:2.5-50mm
Expanded Metal Mesh
- Specification
Specification of Expanded Metal Mesh | ||||||
Sheet Thickness | Opening in Width | Opening in Length | Stem | Roll Width | Roll Length | Weight |
0.5 | 2.5 | 4.5 | 0.5 | 0.5 | 1 | 1.8 |
0.5 | 10 | 25 | 0.5 | 0.6 | 2 | 0.73 |
0.6 | 10 | 25 | 1 | 0.6 | 2 | 1 |
0.8 | 10 | 25 | 1 | 0.6 | 2 | 1.25 |
1 | 10 | 25 | 1.1 | 0.6 | 2 | 1.77 |
1 | 15 | 40 | 1.5 | 2 | 4 | 1.85 |
1.2 | 10 | 25 | 1.1 | 2 | 4 | 2.21 |
1.2 | 15 | 40 | 1.5 | 2 | 4 | 2.3 |
1.5 | 15 | 40 | 1.5 | 1.8 | 4 | 2.77 |
1.5 | 23 | 60 | 2.6 | 2 | 3.6 | 2.77 |
2 | 18 | 50 | 2.1 | 2 | 4 | 3.69 |
2 | 22 | 60 | 2.6 | 2 | 4 | 3.69 |
3 | 40 | 80 | 3.8 | 2 | 4 | 5.00 |
4 | 50 | 100 | 4 | 2 | 2 | 11.15 |
4.5 | 50 | 100 | 5 | 2 | 2.7 | 11.15 |
5 | 50 | 100 | 5 | 1.4 | 2.6 | 12.39 |
6 | 50 | 100 | 6 | 2 | 2.5 | 17.35 |
8 | 50 | 100 | 8 | 2 | 2.1 | 28.26 |
2. Materials:Galvanized steel, carbon steel, stainless steel, aluminum, alloy, etc.
3.Hole shapes: Long holes, round holes, triangle hole, diamond holes, etc.
4.Uses: Fencing: filtration of auto gas engine; the classification and filtration of mine, medicine, cereals and grains; indoor sound insulation, ventilation of grain, etc.
