Home > Products > Sand reclamation plant > blasting cleaning room booth product
blasting cleaning room booth product
- Qingdao
- T/T Credit Card
You May Like
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| Brand Name | ANTAI | Model Number | HPS665 | |
| Feature | Rust / Corrosion Inhibitor | Fuel | Electric | |
| Certification | CB, Other, CB, ISO9001:2008 | Use | Burnishing, Container / Bottle Cleaning, Deflashing, Degreasing, Descaling / Stripping, Sterilizing / Disinfecting | |
| Cleaning Process | Other, steel shot | Cleaning Type | Other, abrasive blasting | |
| Industry Used | Other, Steel pipe and steel pipe products | Material | Metal / Coil | |
| Power(W) | about37kw | Dimension(L*W*H) | 6000*6000*5000mm | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
blasting cleaning room booth product
Our service
Product Introduction
The mechanic recovery blasting room adopts mechanic recovery system to recovery abrasives,and the abrasives can be chosen according to requirements.
The abrasive usage is high and process productivity is also high.
The dust removing system adopts two stages dust removing, and the dust removing efficiency can reaches 99.99%.
The air flow in ventilation in this kind of blasting room can be adjustable to prevent the abrasives from entering cartridge filters.
Thus it can reduce the lost of abrasives and can have a good dust removing efficiency.
The main electrical elements in this blasting room uses Japan/EU/USA brand. They have the advantages of reliability, safety, long life service and easy maintenance.
Composition
Sand blasting room consists of blast chamber, a moving trolley, blasting tank, bucket elevator, separator, screw conveyor, blasting gun, illumination system and dust collector.
It applies to middle and small size of blasting room to do pretreatment jobs such as rough, casting, welding, heating, steel structure, container, transformer shell, special parts and so on.
Technical Parameter
Model | Size of room (mm) | Size of jobs (mm) | Spray gun quantity |
HPS665 | 6000×6000×5000 | 3000×3000×2500 | 2 |
HPS666 | 6000×6000×6000 | 3000×3000×3500 | 2 |
HPS865 | 8000×6000×5000 | 5000×3000×2500 | 2 |
HPS866 | 8000×6000×6000 | 5000×3000×3500 | 2 |
HPS1066 | 10000×6000×6000 | 7000×3000×3500 | 2 |
HPS1566 | 15000×6000×6000 | 12000×3000×3500 | 2 |
HPS1586 | 15000×8000×6000 | 12000×5000×3500 | 2 |
HPS1886 | 18000×8000×6000 | 15000×5000×3500 | 4 |
HPS18108 | 18000×10000×8000 | 15000×7000×5500 | 4 |
Spray nozzle caliber (mm) | Compressed air consumption (m3/min) | Sand consumption (kg/h) | Spraying area (m2/h) |
φ6 | 2.2 | 650 | 6 |
φ8 | 3.92 | 1160 | 10.7 |
φ10 | 6.1 | 1800 | 16.7 |
Product Pictures
1.Equipment painting completed before shipment, With Stretch film to avoid rub off the surface paint, It can used wooden cases packaging according to users requirements.(Key parts such as electric cabinet with shockproof packaging material and then packed in wooden cases. )
2. We have 15 experienced engineers, With 108 skilled workers insure good quality of our machines and prompt delivery.
3.Meanwhile our company has a long-term cooperation with ACL, CSCL, CCNI,CNC, COSCO etc insure the goods to the port on time.
FAQ
1. How many days do you need to produce this machine?
Contact Us
- Qingdao Antai Heavy Industry Machinery Co., Ltd.
- Contact nameyan Ji Chat Now
- Phone86-0532-88138566
- AddressShanghaidongyi Street No297,Jiaonan City,Qingdao City, Qingdao, Shandong
