Home > Products > Sand reclamation plant > CE & After-sales Serviced Q26 Series Sand Blasting Room
CE & After-sales Serviced Q26 Series Sand Blasting Room
- Qingdao
- T/T Credit Card
You May Like
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| Brand Name | ANTAI | Model Number | HPS665 | |
| Feature | Rust / Corrosion Inhibitor | Fuel | Electric | |
| Certification | CB, Other, CB, ISO9001:2008 | Use | Burnishing, Container / Bottle Cleaning, Deflashing, Degreasing, Descaling / Stripping, Sterilizing / Disinfecting | |
| Cleaning Process | Other, steel shot | Cleaning Type | Other, abrasive blasting | |
| Industry Used | Other, Steel pipe and steel pipe products | Material | Metal / Coil | |
| Power(W) | about37kw | Dimension(L*W*H) | 6000*6000*5000mm | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
CE & After-sales serviced Q26 series cleaning sand blasting room
The mechanic recovery blasting room adopts mechanic recovery system to recovery abrasives,and the abrasives can be chosen according to requirements.
The abrasive usage is high and process productivity is also high.
The dust removing system adopts two stages dust removing, and the dust removing efficiency can reaches 99.99%.
The air flow in ventilation in this kind of blasting room can be adjustable to prevent the abrasives from entering cartridge filters.
Thus it can reduce the lost of abrasives and can have a good dust removing efficiency.
The main electrical elements in this blasting room uses Japan/EU/USA brand. They have the advantages of reliability, safety, long life service and easy maintenance.
Use widely: It applies to middle and small size of blasting room to do pretreatment jobs such as rough, casting, welding, heating, steel structure, container, transformer shell, special parts and so on.
HPS Sand blasting Room technical parameter:
Model | Size of room (mm) | Size of jobs (mm) | Spray gun quantity |
HPS665 | 6000×6000×5000 | 3000×3000×2500 | 2 |
HPS666 | 6000×6000×6000 | 3000×3000×3500 | 2 |
HPS865 | 8000×6000×5000 | 5000×3000×2500 | 2 |
HPS866 | 8000×6000×6000 | 5000×3000×3500 | 2 |
HPS1066 | 10000×6000×6000 | 7000×3000×3500 | 2 |
HPS1566 | 15000×6000×6000 | 12000×3000×3500 | 2 |
HPS1586 | 15000×8000×6000 | 12000×5000×3500 | 2 |
HPS1886 | 18000×8000×6000 | 15000×5000×3500 | 4 |
HPS18108 | 18000×10000×8000 | 15000×7000×5500 | 4 |
Spray nozzle caliber (mm) | Compressed air consumption (m3/min) | Sand consumption (kg/h) | Spraying area (m2/h) |
φ6 | 2.2 | 650 | 6 |
φ8 | 3.92 | 1160 | 10.7 |
φ10 | 6.1 | 1800 | 16.7 |
Remarks:
Depend on different jobs from different customers and different productivity requirements, customers may need different size of blasting room.
The above size of blasting room is for customers' reference.
When you have special requirements, we will design blasting room according to your requirements.
1. Open dust collector
2. Open separator
3. Open elevator
4. Open belt conveyor
5. Open light
6. Load workpieces in trolley
7. After trolley arrives at fixed position, close blasting booth door
8. Operators do shot peening, surface cleaning starts
9. After cleaning is finished, open blasting booth door
10. Trolley leave blasting booth, turn over workpieces, repeat step 7, 8, 9
11. Trolley returned to unloading station, unload workpieces.
12. Repeat 6, 7,8,9,10,11 steps
13. If you prepare to stop work, turn to step 14
3D DRAWING
