Pitch 38mm S38K1F12 Agricultural Roller Chain

Agricultural roller chain S38K1F12

Pitch: 38mm

each 4 links per both side K1F12

inner plate height: 21.5mm

width between inner plate: 22mm

plate thickness: 3mm

pin diameter: 9mm

Roller diameter: 16mm

material:  carbon- steel

Inner and out plate,:40Mn  Quenching treatment  HRC 40--48

Attachments: 40Mn Quenching treatment  HRC 38-44

Pin: 30CrMnti   Carbon-Nitriding treatment:  HRN15>=88.9

Bush:  same as 38.4R  10# steel Carbon-Nitriding  HRA76--79

Roller: same as 38.4R   10# steel  carbon- Nitriding  HRA70--76

ZheJiang shenlong Chain Transmission Co.,Ltd is one of biggest professional agricultal chain manufacture factory in zheJiang Province, P.R.china.  We develop and manufacture almost all kind of agrcultural roller chains and conveyor chains.  If you can not find the right chain here,  Call us or send us mail. we will recommend our item to you as you need. also We can develop new mold as you required very soon.  The mold cost will return to you when your item order achived $32780.   All material though strict selected, high quality with best before sales service.
