Blank Pcb Board&gold Plating Pcb&pcb Substrate Fr4 Pcb
- Shenzhen HK
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
4ft 5ft SMD2835LED Tube Pcb 18w T8 Tube Light Pcb T8 Led Tube Pcb Board
-
Bluetooth Audio Receiver Pcb Board
-
Manufacturer of Printed Circuit Board
-
PCB Board Manufacturer and Pcb Board for Projector
-
Riotouch Hot Sales Whiteboard PCB for Education With CE,ROHS Certificate
-
FR4 Double Sided HASL LF Laser Distance Meter Pcb
Product Details
| Place of Origin | Guangdong, China | Brand Name | SYX | |
| Model Number | SYX-A0828B | Number of Layers | Other, 1-20 layers | |
| Base Material | FR4/Aluminum pcb, FR4/Aluminum | Copper Thickness | 1-3oz | |
| Board Thickness | 1.6mm | Min. Hole Size | 0.1mm | |
| Min. Line Width | 3mil | Min. Line Spacing | 3mil | |
| Surface Finishing | ENIG HASL |
Product Description
2 layer pcb lead free for bluetooth speaker
Item | Manufacture Capability |
Material | FR-4 / Hi Tg FR-4 / Lead free Materials (RoHS Compliant) /CEM-3, Aluminum, Metal based/FR1/CEM1 |
Layer No. | 1-- 20 |
Finished Board thickness | 0.2 mm-4.0mm’(8 mil-160 mil) |
Board Thickness Tolerance | ±10% |
Cooper thickness | 0.5 OZ-6OZ (18 um-210 um) |
Copper Plating Hole | 18-40 um |
Impedance Control | ±10% |
Warp &Twist | 0.50% |
Peelable | 0.012"(0.3mm)-0.02’(0.5mm) |
Images | |
Min Trace Width | 0.075mm (3mil) |
Min Space Width | 0.075mm (3mil) |
Min Annular Ring | 0.1mm (4 mil) |
Solder Mask | |
Min Solder Mask Dam | 0.0635 mm (2.5mil) |
Solder mask Clearance | 0.1mm (4 mil) |
Holes | |
Min Hole size (CNC) | 0.1 mm (4 mil) |
Min Punch Hole Size | 0.9 mm (35 mil) |
Hole Size Tol (+/-) | PTH:±0.075mm;NPTH: ±0.05mm |
Hole Position Tol | ±0.075mm |
Plating | |
HASL | 2.5um |
Lead free HASL | 2.5um |
Immersion Gold | Nickel 3-7um Au:1-5u'' |
OSP | 0.2-0.5um |
Certificate | ROHS, SGS, UL, ISO9001: 2008., TS16949 |
Our PCBs are used for wide range of electronic products:
Like Medical devices, Military equippment ,aumtomobile ,CCTV, Power supply, GPS, UPS, Set-top Box,Telecomunication ,LED, etc.
Why choose us as your pcb production partner?
1.We have professional engineer team who will help you to check your design and make your electronic developement go fast.
2. Our rich expierences in pcb production industry, can make you have the best quality with competitive price pcb.
3.Our dedicated&professional sales team can make our factory and engineer team just as a natural extension of your company.
4.After-sales service. you can easily reach our after-sales service just through our sales. every problem you have will get our professional advice and solution.
5.Constant follow up make us have the fast reaction of your requirement.
PCB Manufacture Quote required:
Gerber file or DXP PCB file or Protel file and PCB sepcification: material; board thickness; copper thickness; surface finish; color of silkscreen and solder mask Quantity and time requirement
if you have specific requirements, please feel free to contact us.
We can do the best.
