automatic bottle beverage equipment for juice manufacturing
- shanghai
- T/T
You May Like
-
KYGB Family-controlled beverage filling machine
-
Automatic juice filling machine prices
-
bottle water washing/filling/sealing machine
-
GC normal pressure water filling machine production line
-
XGF fruices juices/tea automatic hot drinking filling Machine
-
small juice filling machine prices for powder mix
Product Details
| Place of Origin | Jiangsu, China | Brand Name | keyuan | |
| Model Number | RGF |
Product Description
Specifications
bottle beverage equipment1.rinser/filling/capping
2.Warranty :1 year
3.capacity:4000-18000bph
4,certificate: CE
Beveage filling machine
A. Water filling machine
B. Carbonated drink filling machine
C. Juice, tea and milk filling machine
D. Alchohol filling machine
A. Water filling machine
It is also be called gravity filling machine with normal pressure. Mineral water, pure water, and any water for drink without gas can use this machine to fill.
automatic bottle beverage equipment for juice manufacturing
Technical parameter:
Model: | XGF12-12-6 | XGF16-12-6 | XGF18-18-6 | XGF24-24-8 | XGF32-32-10 |
capacity (500ml based) | 3000BPH | 4000BPH | 6000BPH | 10000BPH | 12000BPH |
Suitable bottle : | Round bottle or square bottle | ||||
PET bottle: (mm) | (Bottle Diameter): φ50-φ110mm (Height):150-340mm | ||||
Suitable cap specification | PE screw cap | ||||
filling precision: | ≤±5mm | ||||
filling pressure:(Mpa) | ≤0.4Mpa | ||||
Machine power | 4.0 | 4.4 | 5.2 | 5.2 | 6.8 |
Machine size:(mm) | 2150*1650*2250 | 2400*1965*2250 | 2680*2200*2250 | 3000*2200*2250 | 3200*2250*2500 |
weight: (kg) | 2800 | 3500 | 4500 | 5000 | 6000 |
B. Carbonated drink filling machine
It is also called balanced pressure filling machine or gas containing drink filling or isobar filling monoblock. It can fill soda water, coca cola, O2 water, beer and etc.
Technical specifications:
Model: | DCGF16-12-6 | DCGF18-18-6 | DCGF24-24-8 | DCGF32-32-10 | DCGF40-40-12 |
capacity (500ml based) | 2500BPH | 4500BPH | 6000BPH | 8000BPH | 12000BPH |
Suitable bottle : | Round bottle or square bottle | ||||
PET bottle: (mm) | (Bottle Diameter): φ50-φ110mm (Height): 150 -340mm | ||||
Suitable cap specification | PE screw cap | ||||
filling precision: | ≤± 5mm | ||||
filling pressure:(Mpa) | ≤0.4Mpa | ||||
Machine power | 4.4 | 5.2 | 6.2 | 6.8 | 6.8 |
Machine size:(mm) | 2250*1650*2250 | 2600*1965*2250 | 2980*2200*2250 | 3880*2200*2250 | 4000*2650*2500 |
weight: (kg) | 2800 | 3500 | 4500 | 5500 | 6500 |
C. Juice, tea and milk filling machine
Its working principle is hot filling type. The liquid filled in a high temperature in order to kill the bacterial in the drink and prolong the shelf life of products. It can fill fruit jucie both from fresh fruits or from power or concentrated juice. It can also fill drink tea, such as green tea and red tea and power prepared tea.
Technical parameter:
Model: | RXGF16-12-6 | RXGF18-18-6 | RXGF24-24-8 | RXGF32-32-10 | RXGF40-40-12 |
capacity (500ml based) | 3000BPH | 5000BPH | 8000BPH | 10000BPH | 15000BPH |
Suitable bottle: | Round bottle or square bottle | ||||
PET bottle: (mm) | (Bottle Diameter): φ50-φ110mm (Height): 150 -340mm | ||||
Suitable cap specification | PE screw cap | ||||
filling precision: | ≤± 5mm | ||||
filling pressure:(Mpa) | ≤0.4Mpa | ||||
Machine power | 4.4 | 5.2 | 5.2 | 6.2 | 6.8 |
Machine size:(mm) | 2250*1650*2250 | 2600*1965*2250 | 2980*2200*2250 | 3880*2200*2250 | 4000*2650*2500 |
weight: (kg) | 2800 | 3500 | 4500 | 6000 | 7000 |
D. Alchohol filling machine
It fills alchohol, like white wine, vodka, whiskey and cocktail etc.
With capacity: 1000bph, 1500bph, 2000bph, 3000bph, 4000bph, 5000bph, 6000bph etc.
Bottle size: 330ml, 500ml, 600ml, 750ml and 1000ml.
automatic bottle beverage equipment for juice manufacturing
