High Frequency 8kw Double Blister Automatic Packing Machine
- shenzhen
- T/T
You May Like
-
12KW HF Accessories Packaging Machine High Frequency Welder for Sale
-
12KW HF Baby Diapers Packaging Machine High Frequency Welder
-
12KW HF Toothbrush Blister Packing High Frequency Machine for Welding
-
12KW HF Bilster Battery High Frequency Heat Sealing Machine
-
12KW HF Blinder Packing Machine High Frequency Tpu Welding Machine
-
12KW HF Welding Machine Blister Card High Frequency Sealing Machine
Product Details
| Condition | New | Packaging Material | Plastic | |
| Automatic Grade | Automatic | Driven Type | Pneumatic | |
| Voltage | 380v | Power | 8kw | |
| Place of Origin | China | Brand Name | Sinopwr | |
| Model Number | ZG-8KWET | Weight | 1000kg | |
| Certification | CE | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
High frequency 8kw double blister automatic packing machine
1.Adopt splitting device by motor,which the working position can be rotating alternating work.
2.3-5 working positions available, which also can be matched with robot instead of labor feeding or removing material.
3.Equipped with oil pressure supercharging device make the output larger, also finishing the whole process with welding and cutting scraps one-time.
4.American NL-5557 sparkle protector device, which make the mold & products to minimize the damage degree.
5.Adopt Europe type high frequency coaxial resonators when current overloaded then automatically cut off the pressure to protect the oscillation tubes and rectifier.
6.Custom size work tables and welding platen is available
Application:
Used for APET,PETG,PVC,PET,etc material usage of double blister sealing, blister paper card packing, toothbrush packing, with EVA cloth leather, leather,PU material welding and fusing,also be used in PVC, APET, PETG, PP sheet of soft crease box production line (SK)
Specifications:
| Model | ZG-10KW-4ACJ | ZG-12KW-4ACJ | ZG-15KW-4ACJ |
| Power | 10KW | 12KW | 15KW |
| Voltage | 50/60HZ AC380V 3P | ||
| Frequency | 27.12MHz | ||
| Input power | 18KVA | 20KVA | 25KVA |
| Rectifier | silicon diode | ||
| Oscillation tube | E3069RB | E3130RB | 8T85RB |
| Max pressure | 500kg | 800kg | 1000kg |
| Operation mode | pneumatic | ||
| Max distance of electrodes | 200mm | ||
| Press stoke | 150mm | ||
| The size of upper electrode | 300*500mm | 400*500mm | 400*600mm |
| The size of lower electrode | 300*500mm | 400*500mm | 400*600mm |
| The range of temperature | 30~200 oC adjustable | ||
| Welding time | 0---10sdjustable | ||
| Productivity | < 4000times/8hours | ||
