Home > Products > Mineral Separating Equipments > China Spiral Chute Separating Machine for Mineral From Shanghai
China Spiral Chute Separating Machine for Mineral From Shanghai
- Shanghai Qingdao Dalian etc. for spiral chute separating machine for mineral
- T/T L/C D/P D/A Money Gram Credit Card PayPal
You May Like
-
Prior Device Vibrating Screen Separator for Sale
-
Gravity Heavy Mineral Recovery Chrome Spiral Chute Manufacturer
-
Heavy Monazite Spiral Chute for Mineral Recovery
-
Mining Equipment Gold Washing Plant Spiral Chute With High Effective Output
-
Mine Machinery Equipment Horizontal Vibrating Screen
-
Shaking Table Machines for Gold Ore Separating
Product Details
| Type | Other, Sprial Separator, spiral chute | |||
| Production Capacity | According to model | Place of Origin | Shanghai, China | |
| Brand Name | Lipu Brand spiral chute separating machine for mineral | Model Number | 5LL series spiral chute separating machine for mineral | |
| Voltage | According to moel | Power(W) | According to model | |
| Dimension(L*W*H) | According to model | Weight | According to model | |
| Certification | CE,ISO9001:2000 | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Export standard container or as customers requirements (spiral chute separating machine for mineral )
Product Description
Features of spiral chute separating machine for mineral :
1.Simple structurer;
2.Light weight, lower power consumption;
3.Easy operation, reliable operation, easy maintenance;
4.Smaller area, high capacity, and high separating efficiency.
Structure of spiral chute separating machine for mineral :
Spiral chute is mde of feeder, feed chute, spiral flute, bracket, intercepting slot, and supporting frame,etc.
Application of spiral chute separating machine for mineral :
Spiral is used to process iron, stannum, tungsten, tantalum. niobium, gold ore, colliery, monazite, rutile and zircon of the size btween 0.3 and 0.02mm, metals and nonmetal minerals with enough proportion deviation.
Installation of spiral chute separating machine for mineral:
Technical Parameters of spiral chute separating machine for mineral:
| Model | Helix No. | Cycle | Feed Size(mm) | Feed Density(%) | Capacity(t/h) | Area(m2) | Height (m) |
| 5LL400 | 1-2 | 4-5 | 0.02-2 | 30-50 | 0.5-0.2 | 0.25 | 1.5 |
| 5LL600 | 1-2 | 4-5 | 0.02-2 | 30-50 | 0.8-1.2 | 0.5 | 2.6 |
| 5LL900 | 2-3 | 4-5 | 0.03-3 | 30-50 | 2-3 | 1.2 | 3.2 |
| 5LL1200 | 2-4 | 4-5 | 0.03-3 | 30-50 | 4-6 | 2 | 5.23 |
| 5LL2000 | 2-4 | 3-5 | 0.04-4 | 20-45 | 15-40 | 5.7 | 6.6 |
Any change of technical parameters, there is no further notice.
