Tct Saw Blades for Cutting Profiles And Aluminium Bars
- Shanghai or any other Chinese port
- T/T D/P D/A
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | MR TONY | |
| Model Number | AL421 | Blade Material | Alloy Steel | |
| Size | 300X72T |
Product Description
Specifications
1.Unique quality controlling system,every procedure 100% inspected.2.Unique ID code with each blade for tracing use.
Saw blade for cutting aluminium and other non-ferrous profile with wall thickness up to 10 mm, also can cut aluminium bars.
Size available as follows:
FOR NON-FERROUS METAL -- PROFILES AND ALUMINIUM BARS
COD | D(mm) | B/b(mm) | H(mm) | Z | DEVICE |
AL411 | 250 | 3.5/3.0 | 32 | 60 | TCG |
AL421 | 300 | 3.5/3.0 | 32 | 72 | TCG |
AL431 | 350 | 3.5/3.0 | 32 | 84 | TCG |
AL441 | 400 | 3.5/3.0 | 32 | 96 | TCG |
AL451 | 450 | 4.0/3.2 | 32 | 108 | TCG |
AL461 | 500 | 4.0/3.2 | 32 | 120 | TCG |
Similar products as follows:
FOR NON-FERROUS METAL -- THIN WALL PROFILES AND HARD ALUMINIUM ALLOY
COD | D(mm) | B/b(mm) | H(mm) | Z | DEVICE |
AL111 | 250 | 2.8/2.2 | 30/32 | 80 | TCG |
AL112 | 250 | 3.5/3.0 | 30/32 | 80 | TCG |
AL131 | 300 | 3.0/2.5 | 30/32 | 96 | TCG |
AL132 | 300 | 3.5/3.0 | 30/32 | 96 | TCG |
AL141 | 330 | 3.5/3.0 | 30 | 104 | TCG |
AL151 | 350 | 3.5/3.0 | 30/32 | 108 | TCG |
FOR NON-FERROUS METAL -- THIN WALL PROFILES WITH NEGATIVE HOOK ANGLE
COD | D(mm) | B/b(mm) | H(mm) | Z | DEVICE |
AL211 | 250 | 2.8/2.2 | 30/25.4 | 100 | ATB |
AL212 | 250 | 2.8/2.2 | 30/25.4 | 120 | ATB |
AL221 | 300 | 3.0/2.5 | 30/25.4 | 100 | ATB |
AL222 | 300 | 3.0/2.5 | 30/25.4 | 120 | ATB |
FOR NON-FERROUS METAL -- THIN WALL PROFILES
COD | D(mm) | B/b(mm) | H(mm) | Z | DEVICE |
AL311 | 250 | 2.8/2.2 | 25.4/30 | 80 | TCG |
AL312 | 250 | 2.8/2.2 | 25.4/30 | 100 | TCG |
AL313 | 250 | 2.8/2.2 | 25.4/30 | 120 | TCG |
AL321 | 254 | 2.8/2.2 | 25.4/30 | 100 | TCG |
AL322 | 254 | 2.8/2.2 | 25.4/30 | 120 | TCG |
AL331 | 300 | 3.0/2.5 | 25.4/30 | 96 | TCG |
AL332 | 300 | 3.0/2.5 | 25.4/30 | 100 | TCG |
AL333 | 300 | 3.0/2.5 | 25.4/30 | 108 | TCG |
AL334 | 300 | 3.0/2.5 | 25.4/30 | 120 | TCG |
AL341 | 350 | 3.2/2.5 | 25.4/30 | 96 | TCG |
AL342 | 350 | 3.2/2.5 | 25.4/30 | 100 | TCG |
AL343 | 350 | 3.2/2.5 | 25.4/30 | 108 | TCG |
AL344 | 350 | 3.2/2.5 | 25.4/30 | 120 | TCG |
FOR CUTTING PLASTIC
COD | D(mm) | B/b(mm) | H(mm) | Z | DEVICE |
AL511 | 250 | 2.8/2.2 | 30 | 80 | TCG |
AL521 | 300 | 2.8/2.2 | 30 | 96 | TCG |
Main Production Process:
