Home > Products > Hot Work Tool Steel Plate /Plate bar /Round bar > Steel sheet H13/1.2344/8407/SKD61 steel,Hot rolled high speed steel
Steel sheet H13/1.2344/8407/SKD61 steel,Hot rolled high speed steel
- shenzhen
- T/T
You May Like
Product Details
| Grade | skd61 | Standard | AISI, DIN, GB, JIS | |
| Thickness | 20-300MM | Width | 100-610MM | |
| Length | 1000-5800MM | Place of Origin | Guangdong, China | |
| Brand Name | Circle Four | Model Number | skd61 | |
| Application | Mold steel | Technique | Hot Rolled | |
| Special Use | Mold Steel |
Product Description
Specifications
SKD61 steel1.UT grade:SEP1921-84 class C/c
2.100% manufacturer,forge&hot rolled
3.HB290-370,HRC30-52
4.In stock
SKD61 steel
1.Grades: DIN 1.2344; AISI H13, JIS SKD61, GB 4Cr5MoSiV1, ASSAB 8407
2.Chemical composition:
| Standard | C | Si | Mn | Cr | Mo | V | P | S |
| GB/T1299-2000 | 0.32~0.42 | 0.80~1.20 | 0.20~0.50 | 4.75~5.50 | 1.10~1.75 | 0.80~1.20 | ≤0.030 | ≤0.030 |
3.The main properties:
1.Delivery status is Annealed.
2.The hardness after H13 hot work steel annealing Less than or equal 241 HBS.
3.High hot wear resistance.
4.Good toughness, resistance to abrasion.
4.Application:
1. Extrusion mold of aluminum and magnesium, die-casting mold, especially adapted to the mold in large and complicated form.
2.Hot pressing machine mold.
3.The other use of mold.
5.The connection between tempering temperature and hardness:
| Tempering temperature / °C | Hardness/HRC | Tempering temperature/ °C | Hardness/HRC |
| 100 | 59.0 | 500 | 57.5 |
| 200 | 57.0 | 550 | 53.0 |
| 300 | 54.5 | 600 | 49.0 |
| 400 | 54.5 | 650 | 40.0 |
| 450 | 57.5 | 700 | 30.0 |
6. Payment terms:
LC at sight or TT
7. Our advantage
(1) lower price: less producing cost for the small steel factory, so we could supply lower price to our customers.
(2) large stocks: we are the leading steel agency in our country, so we have large stocks for many steel grade and sizes.
(3) quality assurance: 100% according the steel grade standards, MTC available before the shipment.
Photos for your reference:
Our factory informations:
