Best Price 2.0 Megapixel HD-SDI Full HD 1080P SPEED DOME Security CCTV CAMERA

Model

KD-HP93XC20-80-SDI

Camera

Image Sensor

1/2.8” progressive scan Exmor CMOS

Effective Pixels

Approx. 2 Megapixels

Lens

20x optical zoom

f=4.7mm(Wide)~94.0mm(Tele), F1.6~F3.5

Digital Zoom

16x

Horizontal Viewing Angle

55.4.°(Wide)~2.9°(Tele),

Min. Object Distance

10mm(wide) ~ 1000mm(Tele)

Min. Illumination

1.8Lux/F1.6(color);0.02Lux/F1.6(B/W)

Electronic Shutter

PAL/NTSC:1/1 to 1/30,000 s,

White Balance

Auto, ATW, Indoor, Outdoor, Manual

Day/Night

Auto(ICR) / Color / B/W

S/N Ratio

More than 50 dB

Privacy Masking

ON/OFF (up to 24 privacy masking areas)

Video

Video Output

1ch HD-SDI high-definition video (SMPT292/259)

Resolution

1080P (1920 x 1080)

Frame Rate

PAL: 25fps, NTSC: 30fps

Dome Drive

Pan/Tilt Range

Horizontal: 0°~360°endless, Vertical: -2°~90° auto flip 180° to continue monitor

Manual Control Speed

Horizontal: 0.1°~300°/s, Vertical: 0.1°~150°/s

Preset Speed

Horizontal: 400°/s, Vertical: 300°/s

Preset

255

PTZ Mode

5 Auto Pattern, 8 Auto Tour, 5 auto scan

3D Positioning

Yes

Speed Setup

Human-oriented focal Length/ speed adaptation

Info Display

Time, Location, Dome title, Dome coordinates, Temperature, Alarm, and etc.

Power up Action

Auto restore to previous PTZ and lens status after power failure

Idle Motion

Activate preset/scan/tour/ patter if there is no command in the specified period.

Time Task

Auto activation of Preset/Scan/Tour/ Pattern by preset-time

Alarm

7/2 alarm input/output, Triggering Preset/Tour/Pattern/Scan//Alarm output

Protocol

DH-SD, Pelco-P/D, Auto recognition of general protocols

General

Power Supply

AC 24V/3A(±10%)

Power Consumption

12W(Indoor), 50W(Outdoor, heater on)

Working Temperature

-40ºC ~ 60ºC

Working Humidity

<90%

Protection Level

IP67, 4000V thunder, surge and wave-proof protection

Dimension

Φ222(mm) x 324 (mm)

Weight

5.0kg
