Home > Products > DVRs > DVR5204A rearview mirror manual car poe camera car dvr DVR5216A hd dvr manual mobile dvr 2014 china car dvr DVR5208A h 264 dvr
DVR5204A rearview mirror manual car poe camera car dvr DVR5216A hd dvr manual mobile dvr 2014 china car dvr DVR5208A h 264 dvr
Negotiable
/ Piece
5 Pieces(Min.Order)
- 5000 Piece / Pieces per Month
- Shenzhen
- T/T Credit Card
You May Like
-
h264 dahua DVR5804/DVR5808/DVR5816 ZOOM poe china 3g mobile dvr firmware dvr manual hikvision dvr hd sdi dvr OSD hd car dvr kit
-
DVR5104 h.264 dvr china in shen zhen hd sdi 5108/5116H kit hd dvr hikvision dvr 3g mobile dvr firmware poe dvr manual car camera
-
dahua authorized distributor wholesale dahua hd sdi camera dh-hdc-hfw3200c 1080p 2mp cctv analog camera
-
2Megapixel 1080P IR-Bullet HD-SDI Camera HFW3200C
-
hot selling 2mp dahua cctv camera 1080p ip66 bullet camera IR-Bullet HD-SDI Camera HDC-HFW3200C
-
Dahua security 2mp ip camera 1080P IR-Bullet HD-SDI Camera HDC-HFW3200C
Product Details
| Place of Origin | Zhejiang, China | Brand Name | DAHUA or OEM | |
| Model Number | DVR5204A/DVR5208A/DVR5216A |
Product Description
Specifications
DVR5204A rearview mirror manual car poe camera car dvr DVR5216A hd dvr manual mobile dvr 2014 china car dvr DVR5208A h 264 dvrWe sale dahua whole range of products: IP camera, NVR,DVR,encoder and decoder,IP SAN. Low price!
Contact :
DVR5204A rearview mirror manual car poe camera car dvr DVR5216A hd dvr manual mobile dvr 2014 china car dvr DVR5208A h 264 dvr
Overview :
> Up to 4/8/16 cameras with 1080p realtime preview
> H.264 dual-stream video compression
> Full channel @D1(4CIF) realtime recording
> HDMI / VGA / TV simultaneous video output
> All channel synchronous realtime playback, GRID interface & smart search
> 3D intelligent positioning with Dahua PTZ dome camera
> Support 2 SATA HDD up to 8TB, 2 USB2.0
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
| Model | DH-DVR5204A | DH-DVR5208A | DH-DVR5216A | |||
| System | ||||||
| Main Processor | Embedded processor | |||||
| Operating System | Embedded LINUX | |||||
| Video | ||||||
| Input | 4 channel, BNC | 8 channel, BNC | 16 channel, BNC | |||
| Standard | NTSC(525Line, 60f/s), PAL(625Line, 50f/s) | |||||
| Audio | ||||||
| Input | 4 channel, RCA | |||||
| Output | 1 channel, RCA | |||||
| Two-way Talk | 1 channel Input, 1 channel Output(reuse the audio output channel), BNC | |||||
| Display | ||||||
| Interface | 1 HDMI, 1 VGA, 1 TV, 1 Spot, BNC | |||||
| Resolution | 1920×1080, 1280×1024, 1280×720, 1024×768 | |||||
| Display Split | 1/4 | 1/4/8/9 | 1/4/8/9/16 | |||
| Privacy Masking | 4 rectangular zones (each camera) | |||||
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording | |||||
| Recording | ||||||
| Video/Audio Compression | H.264 / G.711 | |||||
| Image Resolution | D1/4CIF(704×576/704×480) / HD1(352×576/352×480) / 2CIF(704×288/704×240) / CIF(352×288/352×240) / QCIF(176×144/176×120) | |||||
| Record Rate | Main Stream: | D1/HD1/2CIF/CIF(1~25/30fps) | ||||
| Extra Stream | CIF/QCIF(1~25/30fps) | |||||
| Bit Rate | 48~4096Kb/s | |||||
| Record Mode | Manual, Schedule(Regular(Continuous), MD, Alarm), Stop | |||||
| Record Interval | 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec | |||||
| Video Detection & Alarm | ||||||
| Trigger Events | Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Spot, Buzzer & Screen tips | |||||
| Video Detection | Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank | |||||
| Alarm Input | 4 channel | 8 channel | 16 channel | |||
| Relay Output | 3 channel | |||||
| Playback & Backup | ||||||
| Sync Playback | 1/4 | 1/4/9 | 1/4/9/16 | |||
| Search Mode | Time/Date, Alarm, MD & Exact search (accurate to second), Smart search | |||||
| Playback Functions | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom | |||||
| Backup Mode | USB Device / Network | |||||
| Network | ||||||
| Ethernet | RJ-45 port (10/100M/1000M) | |||||
| Network Functions | HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, Alarm Server | |||||
| Max. User Access | 20 users | |||||
| Smart Phone | iPhone, iPad, Android, Windows Phone | |||||
| Storage | ||||||
| Internal HDD | 2 SATA ports, up to 8TB | |||||
| Auxiliary Interface | ||||||
| USB Interface | 2ports (1 Rear), USB2.0 | |||||
| RS232 | 1 port, For PC communication & Keyboard | |||||
| RS485 | 1 port, For PTZ control | |||||
| Environmental | ||||||
| Power Supply | DC12V/ 3.3A | |||||
| Power Consumption | 15W(without HDD) | |||||
| Working Environment | -10 ~+55°C / 10~90%RH / 86~106kpa | |||||
| Dimension(W×D×H) | 1U, 375mm×285mm×45mm | |||||
| Weight | 2.35KG(without HDD) | |||||
IE software:
`
Local DVR:
PSS software:
Contact Us
- Shenzhen Guowei Security Electronic Co., Ltd.
- Contact nameFrank Ou Chat Now
- Phone86-755-86677678
- Address6/F, Dong Fang Building 1, No.16 Gaoxin North 6th Road, North High-tech Industrial Park, Nanshan District, Shenzhen, China, Shenzhen, Guangdong
