Express Best Selling 4 Channel 1080N 12v Home Use 4ch H.264 Network Embedded Dvr

System

Model

AVR7804FN

Resolution

4CH D1

Operation System

Embedded LINUX

System Resource

Multiple channels realtime recording,playback,network operation and USB backup

Screen

User Interface

GUI,on-screen menu tips

Screen Display

1/4 screen

Video

Standard

PAL(625 line,50f/s); NTSC(525 line,60f/s)

Compression

H.264(High Profile)

Display Quality

TV: D1   VGA: High definition

Playback Quality

D1/Half-D1/CIF/QCIF

Encode Capacity

100/120fps D1

Decode Capacity

50/60fps D1

NVR Mode

Non-support

Motion detect

Zones:192(16*12)detection zones,Sensitivity:1-6(6 is highest)(only local channel)

Audio

Compression

G.711A

Talk back

Support

Record
    &
Playback

Record Mode

Manual>Alarm>Video Detection>Timing

Local Playback

1~4 channels

Record Search

Time/Date,Alarm,Motion Detection & exact search(accurate to second)

Storage
    &
Backup

HDD Occupation

Video: CIF 4~5G/day/channel, D1 8~10G/day/channel

Audio: 691.2M/day/channel

Record Storage

Local HDD,Network

Backup Mode

Network/USB movable HDD

Interface

Video Input

4ch BNC(1.0Vp-p,75Ω)

Video Output

1ch BNC(1.0Vp-p,75Ω),1ch VGA

Mobilephone View

Support

Audio Input

4ch RCA(200-2800mV,30KΩ)

Audio Output

1ch RCA(200-3000mV,5KΩ)

Alarm Input

Not

Alarm Output

Not

Network

RJ45 10M/100M

PTZ

Support

USB

2 USB2.0

HDD

1 SATA(maximum support 1 x 4T)

Others

Power Supply

12V/3A

Power Consumption

<5W(not include HDD)

Working Temperature

0°C-+55°C

Working Humidity

10%-90%

Atmosphere Pressure

86kpa-106kpa

Dimension

260*210*45mm

Weight

2.5KG
