DC-DC 10-32V to 35-60V Booster Module Booster Electric Car Charging 120W
- NINGBO SHANGHAI HONGKONG
- T/T Credit Card
You May Like
-
1117 3.3V Power Supply Module
-
Digital Light Intensity Module/BH1750FVI IIC Interface/Light Sensor
-
MMA7455 Three-axis Digital Acceleration Sensor Module
-
MS5611-01BA03 Pressure Sensor Module/High Accuracy/Height Sensor Module
-
AM2001 the Single Humidity Sensor(voltage Type Analog Output Module)
-
GY-951 Module, Angle Module, Inclination Electronic Compass Module
Product Details
| D/C | DC-DC 10-32V to 35-60V booster module boost electric car charging 120W | Package | standard package | |
| Model Number | B14 DC-DC | Type | Other, distance measurement | |
| Brand Name | INTEC | Place of Origin | Zhejiang, China |
Product Description

DC-DC 10-32V to 35-60V booster module booster electric car charging 120W
Module parameters
Module properties: non isolated step-up module (BOOST)
Input voltage: 10-32V
Output voltage: (1) continuous adjustable (35-60V) because the adjusting resistance accuracy problem, the actual output voltage may be on the lowest maximum deviation is about 1.5V, the criticalvoltage value need please contact dispensers.
(2) fixed output (35-60V between arbitrary choice), please tell the shopkeeper purchase.
Output current: 5A (MAX)
Input current: 16A (MAX) (more than 10A please strengthen heat dissipation,)
Output power: natural cooling of 80W (MAX), to strengthen the heat 120W (MAX)
The conversion efficiency of 94% typical: (the following test images)
Output ripple: 2% (MAX) 20M bandwidth
Working temperature: industrial grade (-40 DEG to +85 DEG C)(ambient temperature exceeds 40 degrees, please reduce power use, or to strengthen the heat)
Full temperature: 45 C
The typical no-load current: 25mA
Load regulation: + 0.5%
Voltage regulation rate: + 0.5%
The dynamic response speed: 5% 200uS
Short circuit protection: no (please install fuse or circuit protectioninput)
Input reverse connection protection: No, please input series diode.
Wiring terminals: welding.
The matters needing attention:
1.12V wire length 1 meters within the wire is not less than 1.5square meters, more than 1 meters in length if please bold wire.
The 2 module at work at high power, high temperature, plushousing please install fan, small power without fan, make sure the module heat sink temperature should not exceed 80 degrees.
3 the use of input output can not can not take anti short circuit.
4.12V battery discharge voltage is not lower than 10.5V, lithium batteries used in series (a single 3.7V) discharge voltage is not less than 2.7V.
5.VI+ input VI- input cathode, anode and cathode of VO+ output,VO- output negative.
