Adhesive for metal, IC, electronic components

Type

Name

Basic

composition

Performance test

Basic

Application

Special

Function

HYJ-45

Epoxy Adhesive

Epoxy resin

 Shear strength test:

Room temperature

≥4MPa,-60℃≥2Mpa

Apply to bonding of

Metal(Steel,stainless

steel,Aluminum Alloy)

and Nonmetal(celluloid)

Using Temperature -60 - 60℃

HYJ-51

The adhesive of

heat conduction

and insulation

Room and Middle

temperature Heat

curing

Epoxy resin

Shear strength test:

Aluminum-Aluminum

40℃≥15MPa

room temperature≥18Mpa,

150℃≥5MPa

200℃≥2MPa

Heat conductivity:0.8-1.0W/m.K

Surface Resistance≥1.2×1016Ω

Volume resistance≥5.0× 1014Ωcm

breakdown voltage≥20 kv/mm

Special Adhesive of all

kinds of Wall temperature

sensor.

Room or middle temperature

curing,Heat conductive and

insulatingGood waterproof

performance.

GXJ-35

silicone rubber

adhesive

Organic

silicon

rubber

Peel strength:

glass cloth-glass cloth >0.02 MPa,

tensile strength> 0.7MPa

Could be used as Surface

moisture-proof coating.

Apply for moisture-proof bonding of

metal and nonmetal.

Room Temperature curing,

Excellent ablating performance,

Apply to heat resistance and seal.

GXJ-36

silicone rubber

adhesive

Organic

silicon

rubber

 Shear strength test:

Aluminum-Aluminum

Room Temperature>2 MPa

 Apply for heat sealing

bonding of metal and

nonmetal.

Room Temperature curing,

Excellent ablating performance,

Apply to heat resistance and seal.

 GXJ-39

Conductive

silicone

rubber

Organic

silicon

rubber

Shear strength test:

Aluminum-Aluminum

Room Temperature>1 MPa

Resistance

value<10 -2Ω.cm

 To bond the electronic

components

Excellent Conductive performance

Good toughness,Room temperature

fast curing,Excellent ablating

performance.

Dq441J

Conductive

adhesive

Organic

silicon

rubber

Shear strength test:

Aluminum-Aluminum

≥1.0MPa Volume resistance≤0.1Ω.cm

Apply to the bonding of

metal and nonmetal,etc.,

Room temperature ,curing,

Excellent bonding resistance,

Good conductive performance.

Dq442J-86

Multi-function

suit

Organic

silicon

rubber

Shear strength test:

-40℃- 200℃≥1.0MPa Tensile strength

>2.0MPa heat conductivity≤0.15W/m.K

Density≤0.6g/cm2

Apply to the bonding of

metal and nonmetal,etc.,

Excellent Heat conductive

performance

DWJ-72

ultralow

temperature

Heat conductive

and insulating

adhesive

PU

Shear strength test:

aluminium alloy

Room temperature≥8.0MPa.

-196℃≥8.0MPa

heat conductivity>0.45W/m.K

To bond the ultralow

temperature Heat conductive

and insulating parts.

Perfect low temperature

resistance,Heat conductive

and insulating
