Connecting jack and stainless steel sheath automatic assembly machine

Connecting jack and stainless steel sheath automatic assembly machine

Military connector series

Features:

1.The main accessories of the machine adopted FESTOSMC original pneumatic component, precision module are made of S136, other accessories Mitsubishi PLCHMI and other components are using A3 hard chromium plating and AL oxidation treatment

2.The machine is automatically feeding the Jack and stainless steel sheath,inspecting the direction of stainless steel sheath hole,assembling,dotting and testing the insertion and extraction force.

3.It equips with automatic alarming system, which reporting the shortage of incoming material and irregular operations and then stopping to get a solution from operator.

Specification:

Model:JXXF-K021

Capacity: 15-20PCS/Min equal to the capacity of 35-50 people

Power:AC220V 50Hz

Pressure:0.5Mpa±0.1

Weight: 380KG

Size: 1950(L)* 1600(W) * 1800(H) MM

Usage:Available to military Jack automatic shell nosing in aerospace industry

Specification of Jack sheathed automatic crimping machine:

The usage of Jack sheathed automatic crimping machine:

The production is delivered automatically and the materials are loaded through vibration plate.
The hardware accessories will be automatically assembled and it is set with the abilities of
abnormal alarming and information tip guiding,  incoming material's direction inducting ,
lack of materials reminding, production  presetting and counting etc.

Constituent Parts:

Body-frame, hood, display, feeder, vibration plate and so on.

Our advantages:

About Our Company:

Shenzhen Zeyu Automatic Equipment Company (ZEUEE) is a high-tech enterprise specialized in the research and development, manufacturing, marketing,
and service of nonstandard automatic equipment, We are dedicated to provide automatic
solutions with high efficiency, high quality, low cost and fully automatic.

The application are widely used in many fields for automatic production such as standard
fasteners, metal accessories, automotive electronic components, railway electronic components,
 aviation electronic components, civil electronic components, household appliance, locks,
construction hardware, medical instrument parts, cosmetic assembly and lighter assembly, etc.
The automatic solution can effectively solve the increasing severe problems of high cost, poor
efficiency, low quality, recruitment difficult and hard management, etc. It also can save resources,
increase benefit, and achieve the concept of "Harmony and Win-win".
