PUXING PX-555 TRANSCEIVER
- XIAMEN
- T/T Credit Card
You May Like
-
PX-328 Long Distance FM Transceiver
-
PX-358 VHFOr UHF CE approval anytone radio
-
two way radio PX-359 PUXING OEMcheap hot selling radio
-
two way radio PX-888 DTMF ANI encode and decode 5tone 2tone FM radio scrambler CE FCC
-
dual band radio PUXING PX-UV973 hot sell and popular
-
PX-777 VHF Or UHF Handheld 2 Way Radio
Product Details
| Place of Origin | Fujian, China | Brand Name | PUXING | |
| Model Number | PX-555 | Type | Handheld | |
| Dimensions | 100mm*55mm*32mm | Frequency Range | 400-430,430-450,450-470 | |
| Storage Channel | 16 channels | Talk Range | 4-5 kilometers |
Product Description
PX-555 General | |
Frequency Range | UHF:400-430MHz/430-450MHz/450-470MHz |
Channel Capacity | 16 channels |
Channel Spacing | 25KHz(Wide Band) 20KHz(Middle Band) 12.5KHz(Narrow band) |
Phase-locked Step | 5KHz,6.25KHz |
Operating Voltage | 6V DC |
Battery Life | More than 12 Hours (1200mAh), |
Frequency Stability | ±2.5ppm |
Operating Temperature | -20°C +55°C |
Size | 100mm×55mm×32mm (not including antenna) |
Weight | 220 g (with battery, antenna) |
Receiver (ETSI EN 300 086 standard testing ) | |
RF Sensitivity | ≤0.2μV |
Audio distortion | ≤3% |
Adjacent Channel Selectivity | ≥60dB |
Audio Response | +2~-10dB |
Intermodulation Rejection | ≥65dB |
Spurious Rejection | ≥70dB |
Block character | ≥80dB |
Transmitter (ETSI EN 300 086 standard testing ) | |
Frequency Stability | ±2.5ppm |
Output Power | UHF4W |
Max Frequency Deviation | ≤5KHz/2.5KHz |
Audio Distortion | ≤3% |
Adjacent Channel Power | ≥65dB |
Modulation character | +3dB~-3dB |
Spurious Radiation | ≤7.5uW |
Occupied Bandwidth | ≤16KHz |
FEATURES
1) Super-mini, very light
2) Tonal output with loud and clear
3) 16 storage channels for your easy use
4) Computer programming
5) Sturdy and durable
6) Power saving and to extend for using time of batteries
7) Low battery warning
8) Human system engineering, perfect handle
Specifications:
1) Frequencies: 400-430MHz, 430-450MHz, 450-470MHz
2) 16 RF channels
3) Built-in QT
4) Wide-narrow channel bandwidth coverage
5) Time-out timer
6) Two-color LED indicator
7) Weight: 220g (including battery)
8) Dimensions: 100 x 55 x 32mm
9) Battery life: 1300mAh larger capability
