F8-s Patient Monitor

Dimension and weight

Dimension

375mm(W)*330mm(H)*180mm(D)

Weight

standard configuration: 4.4 kg

Operation environment

Power requirements

AC 90-300V, 50/60HZ, 60W

Power

90VA

Temperature

0-40℃

Humidity

0-93% non-condensing

Safety

Meet the requirements of IEC60601 series

Patient range

Adult, neonate and pediatric patients

Performance Specification

Display

12.1 inch (800 x 600 pixel) color TFT LCD rolling and refreshing waveform display

Display mode

Standard, large font, trend table, full lead ECG, Oxy CRG,NIBP trend

Interface

Parameter cable interface

AC power input socket

Battery

Rechargeable battery, 2.2 Ah 12V

Alarm indicator

Visual on-display and integrated alarm light

Audible alarm and personated voice reminding alarm

Data storage

240 hours monitoring data

1024 NIBP records storage

1024 alarm event

Printer

Built-in 50mm thermal printer (option),

2 traces, print speed 25mm/s & 50mm/s

print width:50mm

ECG

Leads type

3(option)/5-lead : I, II, III, aVR, aVL, aVF, V

Sweep speed

12.5mm/s, 25mm/s 50mm/s

Gain selection

×0.25, ×0.5, ×1, ×2

ECG waveform

1 channels

Operation mode

Diagnostic, monitor, surgery

Heart rate range

0 -300bpm

Accuracy

1bpm or ±1% whichever is great

Alarm range

Audible and visual alarm, adjustable

ST/ arrhythmia

Real time S-T segment detection, pace detection and arrhythmia analysis

Protection

Against electrosurgical interference and defibrillation

Respiration (RESP)

Method

Thoracic impedance

Operation mode

Auto

Measurement range

Adult: 0-120BrPM; neonatal /pediatric: 0-150BrPM

Apnea alarm

Yes

Alarm

Yes, audible and visual alarm ,alarm events recallable

NIBP

Method

Automatic oscillometric

Operation mode

Manual/Automatic/STAT

Auto measure time

Adjustable

Measurement unit

mmHg / kPa selectable

Test interval

1-480 minutes

Measurement range

Adult: 0-300 mmHg ;

Child: 0-240 mmHg ;

Infant: 0-150 mmHg

Over-pressure protection

Double safety protection

Accuracy of blood pressure      measurement

The mean error shall be less than±5mmHg

the standard deviation shall be less than 8mmHG

Resolution

1 mmHg

SPO₂

Measurement range

0%-100%

Resolution

1%

Accuracy

±2% (70-100%, adult/pediatric, non-motion )

±3% (70-100%, neonate, non-motion )

±3% (70-100%, adult/pediatric/neonate, motion )

0-69% unspecified

Alarm range

1-100%

Pulse rate

Pulse range:

20-300bpm

Accuracy:

±3bpm(non-motion)

±5bpm(motion )

Temperature (TEMP)

TEMP range

0-50℃

Resolution

0.1 ℃

Accuracy

±0.1℃ (excluding the sensor)

Channel

Single channel.
