sale 2014 High performance XCMG engine 50 ton new truck crane for sale

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port SHANGHAI/QINGDAO
Payment TermsT/T D/P D/A Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Rated Loading Capacity	50 ton
Rated Lifting Moment	1509KN.M	Max. Lifting Load	50 ton
Max. Lifting Height	55.8m	Span	54m
Place of Origin	Jiangsu, China	Brand Name	XCMG
Model Number	QY50K	Certification	ISO/CE
Warranty	1 year	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

sale 2014 High performance XCMG engine 50 ton new truck crane for sale

Product Description

Features of sale 2014 High performance XCMG engine 50 ton new truck crane for sale

XCMG Truck Crane (QY50K-II) is one of the best performance truck crane. Cranes of the XCMG are very popular in the word. The innovative jib system adopts embedded block, plug-in boom head and international advanced U section jib, which has excellent lifting performance and safe and reliable lifting work.
The unique stretch and retract technique avoids the bend of the core pipe and cylinder and the break of the boom caused by misoperation, improving the safety of the operations.
Eight patent techniques ensure the smooth, high efficiency and energy conservation of the lifting, rotation, and luffing systems.
Adopt the new hydraulic motor with big torque starting point, making the secondary lifting safer.
The torque limiter adopts colorful LCD display, realizing the intelligence of the failure diagnosis. The precision is ahead of the industry.
The humanity design makes the cab and control cab more spacious, and easy to operate.
Six unique manufacturing technologies ensure the high quality.

Parameters of sale 2014 High performance XCMG engine 50 ton new truck crane for sale

xcmg 50 ton truck crane qy50b

Classificatory	Item	Unit	Parameter
Dimensions	Overall length	mm	13270
	Overall width	mm	2750
	Overall height	mm	3300
Weight	Dead weight in travel state	kg	39870
	Front axle load	kg	13935
	Rear axle load	kg	25935
Power	Engine model		WD615.46
	Engine rated output	kW/(r/min.)	266/2200
	Engine rated torque	N.m/(r/min.)	1460/1400
Travel	Max. travel speed	km/h	78
	Min. turning diameter	mm	24000
	Min. ground clearance	mm	251
	Approach angle	°	16
	Departure angle	°	10
	Braking distance(at 30km/h)	m	10
	Max. gradeability	%	46
	Fuel consumption of per 100km	L	48
Lifting performance	Max.total rated lifting load	t	50
	Min. rated working radius	m	3
	Turning radius at swing table tail	m	3.8
	Max. load moment( Base boom)	KN.m	1509
	Fully extended boom	KN.m	631
	Outrigger extension distance
	Lateral/Longitudinal	m	6.6/5.45
	Lifting height (Base boom)	m	11.27
	extend boom	m	40.31
	Fully-extend boom+Jib	m	55.8
	Jib offset	°	01530
Working speed	Boom elevating time	s	120
	Boom full extending time	s	184
	Max. swing speed	r/min	2
	Outrigger beam extending/retracting synchronously	s	40/42
	Outrigger jack extending/retracting synchronously	s	40/42
	Main winch with full /no load	m/min	70.8/118
	Auxiliary winch with full /no load	m/min	70.8/118
