Home > Products > 3 point linkage kit > Brohawk 3 Point Linkage Kit
Brohawk 3 Point Linkage Kit
- Mumbai
- T/T L/C D/P D/A
You May Like
Product Details
| Place of Origin | Punjab, India | Brand Name | Brohawk | |
| Model Number | BKT-KU, BKT-IS |
Product Description
3 Point Linkage Kit For Kubota Tractor specification:-
This Linkage kit fits to small tractors ranging fron 14 H.P to 20 H.P. Tractors. Good for grey market tractors without 3 point hitch. The 3 point linkage kit is coated with non corrosive paint and heavily electroplated.
Tractor Lift Arm ——- 2 Nos.—- Hole to Hole — 20.5 inch
Top Link —- 1 No.—- Hole to Hole–17 inch– 22 inch, Ball End Hole – 3/4 inch
Fixed Vertical Stabilizer ——– 1 No.—– Hole to Hole — 15.5 inch
Adjustable Vertical Stabilizer —– 1 No.—- Hole to Hole — 15 inch to 18 inch
Rod with Spacer ——– 1 No.—– OD 7/8 inch and Total Length 18.5 inch
Lynch Pin with Chain——— 2 Nos.
Chain Stabilizer———-2 Nos.—– According to tractor lift arm.
3 Point linkage Kit for Iseki Tractor specification:-
This Linkage kit fits to small tractors ranging from 14 H.P to 20 H.P. Tractors. Good for grey market tractors without 3 point hitch. The 3 point linkage kit is coated with non corrosive paint and heavily electroplated.
Tractor Lift Arm ——- 2 Nos. —- Hole to Hole — 20.5 inch
Top Link —- 1 No. —- Hole to Hole–17 inch– 22 inch, Ball End Hole – 3/4 inch
Fixed Vertical Stabilizer ——– 1 No. —– Hole to Hole — 15.1/2 inch
Adjustable Vertical Stabilizer —– 1 No. —- Hole to Hole — 15 inch to 18 inch
Rod with Spacer ——– 1 No.—– OD 7/8 inch and Total Length 18.5 inch
Lynch Pin with Chain——— 2 Nos.
Chain Stabilizer———-2 Nos. —– According to tractor lift arm.
3 Point Linkage Kit Images
