High quality 0.5w 2016 Green SMD LED
USD $0.02 - $0.03
/ Piece
10000 Pieces(Min.Order)
- 1000000 Piece / Pieces per Month
- Shenzhen
- Credit Card
You May Like
Product Details
| Model Number | FD-2016W | Chip Material | AlGaInP | |
| Emitting Color | Other, High quality 0.5w 2016 Green SMD LED | Luminous Intensity | 50-55lm 55-60LM 60-65LM 65-70LM | |
| Luminous Flux(lm) | 45-55lm | Optical Attenuation(%) | 0.03% | |
| Power | Other, 0.5W, High quality 0.5w 2016 Green SMD LED | Power Dissipation | 300 | |
| Color Rendering Index(Ra) | 85 | Color Temperature | 520-525 | |
| Operating Temperature(℃) | -40, +80 | Storage Temperature(℃) | -40, +80 | |
| Place of Origin | Guangdong, China | Brand Name | FEDY | |
| Certification | CE |
Product Description
High quality 0.5w 2016 Green SMD LED
Product Description
High quality 0.5w 2016 Green SMD LED
| Part No. | Color | Wavelength/ CCT | Intensity | Wattage |
| FD-2016W-0.5 | White | 1700k -25000K | 50LM | 0.5W |
| FD-2016R-0.5 | Red | 620-630nm | 20LM | 0.5W |
| FD-2016Y-0.5 | Yellow | 588-595nm | 20LM | 0.5W |
| FD-2016B-0.5 | Blue | 460-470nm | 20LM | 0.5W |
| FD-2016G-0.5 | Green | 520-525nm | 35-40LM | 0.5W |
Company Information
1. FEDY is a professional manufacturer of Power led, led diode since 2000
2. Class A quality with 3 years warrany for all items.
3. Orignal Epistar/Bridgelux chips with 100% Class A grade.
4. All leds 100% QA passed before shipped.
5. Fully automatic production machine and quality checking machines insure great quality of goods , and fast delivery .
Quality Control
. Epistar chips . Class A quality . Square type , First selection
2. Super low decay version
3. Anti-static built in
4. Anti-high temperature built in
5. Lifespan > 80 000hours
6. Warranty : 3 years
7. CE ROHS
8. ESD protection .
9. Specs of LED made according to your request . Engineers with 30 years experience insure you 100% satisfied.
Our Services
1.Highest quality
2. Best price
3. Fast response
4. Thousand types of led diode , various plan of led for your project
Packaging & Shipping
Dip LED: ESD bag, Reel& Tape
High power led : ESD box .ESD bag, Tube
Super flux led : ESD bag. Tube
SMD LED : Reel
| SMD5050 | ||||
| Part No. | Color | Wavelength/ CCT | Intensity | Voltage |
| FD-5050W-A | 1500-30000k | 14-16lm | 3.0-3.4V | |
| FD-5050W-B | 16-18lm | 3.0-3.4V | ||
| FD-5050W-C | 18-20lm | 3.0-3.4V | ||
| FD-5050W-D | 22-24lm | 3.0-3.4V | ||
| FD-5050R | Red | 620-630nm | 800-1000mcd | 1.9-2.3V |
| FD-5050R-2 | Red ( Super bright) | 1200-1500mcd | ||
| FD-5050R-3 | Red ( Ultra bright ) | 1800-2200mcd | ||
| FD-5050Y | Yellow | 588-595nm | 800-1000mcd | 1.9-2.3V |
| FD-5050Y-2 | Yellow ( Super bright ) | 1800-2200mcd | ||
| FD-5050B | Blue | 460-470nm | 800-1000mcd | 3.0-3.2V |
| FD-5050B-2 | Blue ( Super bright) | 1500-1800mcd | ||
| FD-5050G | Green | 520-525nm | 2000-2500mcd | 3.0-3.2V |
| FD-5050G-2 | Green ( Super bright ) | 3000-3500mcd | ||
| FD-5050PI | Pink | 800-1000mcd | 3.0-3.2V | |
| FD-5050PI-2 | Pink ( Super bright ) | 1000-1500mcd | ||
| FD-5050Piu | Purpleish pink | 800-1000mcd | 3.0-3.2V | |
| FD-5050Piu-2 | Purpleish pink (Super bright ) | 1000-1500mcd | ||
| FD-5050Ib | Ice Blue | 25000-30000k | 14-16lm | 3.0-3.2V |
| FD-5050Ib-2 | 18-20lm | |||
| FD-5050A | Amber/Orange | 600-610nm | 800-1000mcd | 1.9-2.3V |
| FD-5050UV | UV | 395-400-405nm | 200-300mcd | 3.2-3.6v |
| FD-5050IR | Infrared | 940nm | 1.5-1.9V | |
| FD-5050IR2 | Infrared | 850nm | 1.5-1.9V | |
| FD-5050RGB | RGB | R: 620-625nm G: 515-525nm B: 460-470nm | 5000mcd | R: 1.9-2.1v G: 3.0-3.2v B: 3.0-3.2v |
| FD-5050RGB-2 | RGB ( Ultra bright ) | 8000-10000mcd | ||
| FD-5050RGBW | RGBW | 4 color in one | ||
| FD-5050RRGB | RRGB | 4 color in one | ||
| SMD3528 | ||||
| Part No. | Color | Wavelength/ CCT | Intensity | Voltage |
| FD-3528R | Red | 620-630nm | 600-800mcd | 1.9-2.3V |
| FD-3528Y | Yellow | 588-595nm | 300mcd | 1.9-2.3V |
| FD-3528Y-2 | Super bright Yellow | 600mcd | 1.9-2.3V | |
| FD-3528Y-3 | Ultra bright Yellow | 800-1000mcd | 1.9-2.3V | |
| FD-3528B | Blue | 460-470nm | 400-500md | 3.0-3.4V |
| FD-3528G | Green | 520-525nm | 1200-1500mcd | 3.0-3.4V |
| FD-3528PI | Pink | 500-600mcd | 3.0-3.4V | |
| FD-3528A | Amber | 600-605nm | 300mcd | 1.9-2.3V |
| FD-3528UV | UV | 395-400-405nm | 200mcd | 3.0-3.4V |
| FD-3528IR | Infrared | 940nm | 10-14mil | 1.5-1.7 |
| FD-3528IR2 | Infrared | 850nm | 10-14mil | 1.5-1.7 |
| FD-3528RGB | RGB | Standard | 2000mcd | |
| FD-3528RGB-2 | RGB | Super bright | 3000mcd | |
| Part No. | Color | Wavelength/ CCT | Intensity | Voltage |
| FD-3014W-A | White | 2500K up to 20000K | 9-16lm | 3.0-3.2V |
| FD-3014B | Blue | 460-470nm | 300-600mcd | 3.0-3.2V |
| FD-3014G | Green | 520-525nm | 1600-2000mcd | 3.0-3.2V |
| FD-3014R | Red | 620-630nm | 200-500mcd | 1.9-2.3V |
| FD-3014Y | Yellow | 588-595nm | 300-500mcd | 1.9-2.3V |
| FD-3014A | Amber | 600-610nm | 300-500mcd | 1.9-2.3V |
| FD-3014IR | Infrared | 940nm | 3.2-3.4V | |
| FD-3014IR2 | Infrared | 850nm | 3.2-3.4V |
| Part No. | Color | Wavelength/ CCT | Intensity | Watt avaialble |
| FD-5730W-A | White | 2500K up to 20000K | 40-45lm | 0.5w |
| FD-5730W-B | White | 45-50lm | ||
| FD-5730W-C | White | 50-55lm | ||
| FD-5730W-D | White | 55-60lm | ||
| FD-5730W-E | White | 60-65lm | ||
| FD-5730B | Blue | 460-470nm | / | 0.2w 0.5w |
| FD-5730G | Green | 520-525nm | / | |
| FD-5730R | Red | 620-630nm | / | |
| FD-5730Y | Yellow | 588-595nm | / | |
| FD-5730A | Amber | 600-610nm | / | |
| FD-5730IR | Infrared | 940nm | ||
| FD-5730IR2 | Infrared | 850nm |
| Part No. | Color | Voltage | Current | Intensity | Emitting angle |
| FD-3030W-3v | White Cool white Warm white | 3v | 350mA | 110-130lm | 120degree |
| FD-3030W-6v | 6v | 150mA | 110-130lm | 120degree | |
| FD-3030W-9v | 9v | 100mA | 110-130lm | 120degree | |
| FD-3030W-18v | 18v | 60mA | 110-130lm | 120degree | |
| FD-3030W-24v | 24v | 40mA | 110-130lm | 120degree | |
| FD-3030W-27v | 27v | 30mA | 110-130lm | 120degree | |
| Part No. | Color | Voltage | Current | Intensity | Emitting angle |
| FD-3030R-3V | Red 620-625nm | 3v | 350mA | 40lm | 120degree |
| FD-3030G-3V | Green 520-525nm | 3v | 350mA | 100lm | 120degree |
| FD-3030Y-3V | Yellow 588-595nm | 3v | 350mA | 40lm | 120degree |
| FD-3030B-3V | Blue 460-470nm | 3v | 350mA | 25lm | 120degree |
| FD-3030UV-3V | UV 400-410nm | 3v | 350mA | 10lm | 120degree |
| Part No. | Voltage | Current | Intensity | CCT |
| FD-2835HV3-0.5 | 3-3.2V | 150mA | 65lm | 2600k -12000K |
| FD-2835HV9-0.5 | 9-10V | 30-60mA | 28-60lm | |
| FD-2835HV18-0.5 | 18-20V | 30mA | 75lm | |
| FD-2835HV36-0.5 | 26-37V | 15mA | 75lm | |
| Part No. | Color | Wavelength/ CCT | Intensity | Emitting angle |
| FD-1206W | White | 2500K up to 20000K | 700-800mcd | 120degree |
| FD-1206R | Red | 620-630nm | 100-200mcd | 120degree |
| FD-1206Yg | Yellowgreen | 568-574nm | 30-50mcd | 120degree |
| FD-1206Y | Yellow | 588-595nm | 100-150mcd | 120degree |
| FD-1206O | Orange | 600-610nm | 100-200mcd | 120degree |
| FD-1206B | Blue | 460-470nm | 180-250mcd | 120degree |
| FD-1206G | Green | 520-525nm | 600-800mcd | 120degree |
| FD-1206Pi | Pink | X0.38 Y0.108 | 120-150mcd | 120degree |
| FD-1206Pu | Purple | 395-400nm | 80-100mcd | 120degree |
| Part No. | Color | Wavelength/ CCT | Intensity | Voltage |
| FD-0805W | White | 2500K up to 20000K | 9-16lm | 3.0-3.2V |
| FD-0805B-1 | Blue | 460-470nm | 200-300mcd | 3.0-3.2V |
| FD-0805G-1 | Green | 520-525nm | 500-800mcd | 3.0-3.2V |
| FD-0805R-1 | Red | 620-630nm | 200-300mcd | 1.9-2.3V |
| FD-0805B-2 | Blue | 460-470nm | 300-500mcd | 3.0-3.2V |
| FD-0805G-2 | Green | 520-525nm | 800-1500mcd | 3.0-3.2V |
| FD-0805R-2 | Red | 620-630nm | 300-500mcd | 1.9-2.3V |
| FD-0805Y | Yellow | 588-595nm | 200-300mcd | 1.9-2.3V |
| FD-0805A | Amber | 600-610nm | 200-300mcd | 1.9-2.3V |
| FD-0805IR | Infrared | 940nm | 3.2-3.4V | |
| FD-0805R2 | Infrared | 850nm | 3.2-3.4V | |
| Part No. | Color | Wavelength/ CCT | Intensity | Voltage |
| FD-0603W | White | 2500K up to 20000K | 9-16lm | 3.0-3.2V |
| FD-0603B-1 | Blue | 460-470nm | 200-300mcd | 3.0-3.2V |
| FD-0603G-1 | Green | 520-525nm | 500-800mcd | 3.0-3.2V |
| FD-0603R-1 | Red | 620-630nm | 200-300mcd | 1.9-2.3V |
| FD-0603B-2 | Blue | 460-470nm | 300-500mcd | 3.0-3.2V |
| FD-0603G-2 | Green | 520-525nm | 800-1500mcd | 3.0-3.2V |
| FD-0603R-2 | Red | 620-630nm | 300-500mcd | 1.9-2.3V |
| FD-0603Y | Yellow | 588-595nm | 200-300mcd | 1.9-2.3V |
| FD-0603A | Amber | 600-610nm | 200-300mcd | 1.9-2.3V |
| FD-0603IR | Infrared | 940nm | 1.5-1.7 | |
| FD-0603IR2 | Infrared | 850nm | 1.5-1.7 | |
| FD-0603UV | UV | 395-400 400-405 | 3.2-3.6 | |
| FD-0603Pi | Pink | 3.0-3.4 |
