MIC-A4 2L wide mouth jar pet blow machine plastic jerry can production blow molding machine 1 liter blow molding machine price
- Ningbo/Shanghai
- T/T
You May Like
-
MIC-8Y Micmachinery semi-automatic blow molding machine for PET jar
-
Micmachinery widely used bottle blowing process plastic blow molding machine water bottle blowing machine
-
Micmachinery oversease service PET bottle manual blow molding machine mineral water bottle blowing machine for sale
-
Micmachinery cheap price soft drink bottle blowing machine plastic blow molding machine PET bottle making machine
-
Micmachinery good quantity PET bottle making machine semi-automatic bottle blow moulding machines plastic blow molding machine
-
Micmachinery factory direct sale pet bottle making machine stretch blow moulding machine PET bottle manual blow molding machine
Product Details
| Condition | New | Application | Bottle | |
| Plastic Processed | PET | Blow Moulding Type | Stretch Blow Moulding | |
| Automatic | Yes | Place of Origin | Zhejiang, China | |
| Brand Name | MIC | Model Number | A4 | |
| Voltage | 380V | Power(W) | 13Kw | |
| Dimension(L*W*H) | 1900*1860*1930mm | Weight | 3000kg | |
| Certification | CE | Warranty | 1-2 years | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
MIC-A4 2L wide mouth jar pet blow machine plastic jerry can production blow molding machine 1 liter blow molding machine price
Parameters of wide mouth jar pet blow machine plastic jerry can production blow molding machine 1 liter blow molding machine price
| Model | ITEM | MIC-A2 | MIC-A4 |
| Productivity | Depend on bottle design | 1800-2000PCS/H | 3200-4000PCS/H |
| Product type | Volume | ≤2L | ≤2L |
| Body diameter | ≤100mm | ≤100mm | |
| Height | ≤310mm | ≤310mm | |
| Neck diameter | ≤38mm | ≤38mm | |
| Mould | Cavity | 2 | 4 |
| Mold thickness | 240mm | 240mm | |
| Mold size | 260*240*370mm | 510*240*360mm | |
| Main machine power | Electrical source power | 380V/220V 50/60HZ 3Phase | 380V/220V 50/60HZ 3Phase |
| Power | 25kw | 49kw | |
| Really use power | 6.5kw | 13kw | |
| Air system | HP air compressor | 1.4 m3/min 3.0Mpa | 2.0 m3/min 3.0Mpa |
| LP air compressor | 1.0 m3/min 1.0Mpa | 1.6 m3/min 1.0Mpa | |
| Air Tank | 0.6m3 3.0Mpa | 0.6m3 3.0Mpa | |
| Air dryer | 1.0m3/min 3.0Mpa | 2.0m3/min 3.0Mpa | |
| Cooling water | Water Chiller | 3HP | 3HP |
| Machine | Size(L*W*H) | 1900*1280*1930mm | 1900*1860*1930mm |
| Weight | 2000kg | 3000kg | |
| Preform unscrambler | Size(L*W*H) | 2000*950*2480mm | 2000*950*2480mm |
| Weight | 250kg | 250kg |
Features of wide mouth jar pet blow machine plastic jerry can production blow molding machine 1 liter blow molding machine price
MIC-A4 wide mouth jar pet blow machine plastic jerry can production blow molding machine 1 liter blow molding machine price is suitable for producing PET plastic containers and bottles in all shapes . it is widely used to produce the carbonated bottle,mineral water bottle, pesticide bottle,oil bottle,cosmetics bottle ect.
Reasonable design , full automaticlly control, save power and labor.
Adopting high quality components.
Feeding system carries the preforms by robot arms automatically.
Infrared oven adopts the quartz lamp to heat the PET tube.
Full automatic process with low investment,high efficiency , quick and safe for operating,easy for maintenance
Machine detail
Details picture of 1L wide mouth bottle blow moulding machine
Setup of 1L wide mouth bottle blow moulding machine
Full automatic blowing molding machine
Pneumatic part: 1. Valve 2. Cylinder 3 Brand: SMC
Electric part: 1. PLC 2. Operating system: 3. Brand: LG 1. Relay: OMRON
Note: All of the electrical components adopt CE, UL, CCC approved international advanced high-tech product.
Full automatic blow molding machine ( machines to make plastic bottles ) is suitable for producing PET plastic containers and bottles in all shapes.
It is widely used to produca the carbonated bottle,mineral water,pesticide bottle,oil bottle,cosmetics bottle, wide-mouth bottle ect.
oil bottle blow moulding machine is packed with export wooden case
Detail picture of oil bottle blow moulding machine workshop
We will offer our technician for oversea full automatic oil bottle blow moulding machine installation and training service.
we can also provide our Sales as translator to your site help the installation and Training. Only to provide the local transportation, accommodation, air tickets (round trip) for Sales will be fine.
Thank you for choosing MICMachinery Company.
We have doing oil bottle blow moulding machine for 8 years, after the company recombination, the oil bottle blow moulding machine we sold to europe, africa, the america states and south america. we can guarantee our oil bottle blow moulding machine for years running with steady working.
We provide 8 hour action, 24hours solution after sale service, in order to avoid the time difference bring the economic and trust lost to our clients.
Company Information
Company Name | Mic Machinery.Co.,Ltd (Hangzhou) |
Business Type | Manufacture & Trading |
Location | ZheJiang,China |
Products Cetifications | CE SGS |
Main Markets | Europe, South & North America,Africa |
Experience | Over 8 years experience in machine design and manufacturing Over 6 years in exporting Factory Turnkey projects (done): over 20 cases |
Oversea Projects | Greece, albania, france, turkey, algeria, Sudan, Saudi Arabia ETC |
Delivery time | 30-75 Days according to different project |
Guarantee | 1 or 2 years Guarantee according to different project |
Control Cabinet Voltage | 220v/380v, 3 phase, 50Hz (Mainly) / Customized |
Packaging | Wooden Case (export) |
FAQ of oil bottle blow moulding machine
The causes for defective products and solutions:
Defects | Causes | Solutions |
Pearly luster appears on the product and the gate part on the bottom deviates the center | 1The heating temperature for the pre-form is too low | Raise heating temperature |
2Blowing time is too early | Prolong the blowing time | |
3Heating of pre-form is not uniformed | Check if the rotating electric motor of the oven works | |
4The linear velocity for pulling pre-form is too low | Raise working pressure flux of pre-forms | |
The product can’t be formed | 1 Insufficient pressure | Raise pressure |
2Insufficient blowing flux | Raise blowing flux | |
3Stretching rate is too high | Redesign stretching rate | |
4Blowing valve is damaged | Replace the valve | |
Wall thickness of products is not uniform | 1Wall thickness of pre-forms is not uniform | Replace pre-forms |
2Stretching rate is too low | Redesign stretching rate | |
The neck of the product shrinks into a loop | Blow time is too late | Advance blowing time |
The bottom of the product does not form or is too thick | 1Blow time is too late | Advance blowing time
|
2 Heating temperature on the bottom of pre-forms is too low | Raise corresponding heating temperature | |
Transparency of products is not good | 1The pre-form is not transparent enough | The plastic material is not dry enough |
2The second-time heating temperature for the pre-form is too high | Reduce the heating temperature and heating time | |
3There is moisture in the blowing air | Check if filter outlet is obstructed. |
