High Efficency LED Street Light Replacing 80-120w HPS

FOB Price

US$ 107 - 140 / Piece

1 Piece(Min. Order)

Port Shenzhen
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

LED Light Source	High quality Bridgelux 700Ma 45Mi	Input Voltage(V)	AC90-305V
Lamp Power(W)	40	Lamp Luminous Flux(lm)	3720
Lamp Luminous Efficiency(lm/w)	93	Color Temperature(CCT)	Cool White
Working Temperature(℃)	-30, 50	Working Lifetime(Hour)	50000
Lamp Body Material	Aluminum Alloy	IP Rating	Other, IP68, IP68
Certification	CCC, CE, ETL, FCC, UL	Warranty(Year)	5
Place of Origin	Guangdong, China	Brand Name	CESP
Model Number	CES-L150

Product Description

Specifications

high efficiency low power consumption
environment friendly, no IR, no UV
long lifespan over 50000H
Wide AC input
CE, UL,RoHS

Note	ITEM NO.	DESCRIPTION	TOTAL POWER	Reflector/wide angle	NOMINAL LUMENS	DRIVE CURRENT	# OF LEDS	SYSTEM EFFICACY
UL & CUL /CE Certify	CES-L200	Replacing 600-800w HPS	185	Wide angle	16,650	350 mA	144	90 LM/W
UL & CUL /CE Certify	CES-L150	Replacing 400-500w HPS	150	Optional for both	13,500	350 mA	120	90 LM/W
CE Certify	CES-L120	Replacing 300-400w HPS	120	Optional for both	11,160	300 mA	120	93 LM/W

*actual product may vary from picture show.

LED Street Light: Pole Mount

LED LIGHT ENGINE

Ø High quality Bridgelux 700Ma 45Mil

Ø Efficacy : up to 150lm @ 350Ma (per watt)

Ø Rated Life of 100,000+ hrs

Ø Operation temp: -30 ºC to +50 ºC

Ø No toxic chemicals/Rohs compliant

Ø 70%-80% saving compare to HPS/MH

PRODUCT FEATURE

Ø 5 years warranty

Ø Highest Ingress Protection rating : IP68

*Total power consumption may vary due to installation location.

Perfection is the Goal

APPEARANCE

Ø Material: Die Cast Aluminum

Ø Light Color option: Cool White

Warm White

Custom color

Ø LENS: Super Clear Tempered Glass

ELECTRICAL CHARACTERISTICS

Ø Wide AC input: 90-305 VAC

Ø (UL marking: 100-240VAC/277VAC)

Ø Power Factor: ~0.98

Ø Total Harmonic Distortion: < 10%

Ø Surge protection: IEC/EN 61000-4-5

Ø EMC test standard
